Quatech SDS User's Manual
Figure 8 illustrates the Quatech
Install Wizard's Welcome
screen.
Step Procedure
Step 5 Click the Next button to continue.
Figure 9 illustrates the Prepare
to Install prompt. Be sure to
read this screen carefully
before proceeding.
Note: Press the Help key for
additional information as you
go through the installation
procedure.
Step Procedure
Step 6 Connect the Ethernet port on your SDS to
one of the following:
Desired installation location,
Hub on your local subnet, or
Network Interface Connection (NIC)
on your computer using an Ethernet
crossover patch cable.
October 2006

Figure 7 - Welcome screen

Figure 8 - Prepare to Install screen

940-0183-154
Installing the device drivers
Description
The Prepare to Install screen displays.
Continue with □ Step 6.
Description
If you cannot immediately attach the SDS
to the target installation site, temporarily
attach it to the local hub or your computer's
NIC for configuration purposes.
Notes: Use a CAT5 or better Ethernet cable
to attach the SDS to your network.
If your SDS is pre-configured for your
network, attach it now to the appropriate
subnet location.
Continue with □ Step 7.
Page 17
