Ber Performance (Turbo); Figure 7-4. Dmd2050E B/O/Qpsk Ber Performance (Turbo) - Comtech EF Data DMD-2050E Installation And Operation Manual

DMD2050E Universal Satellite Modem
7.12.4

BER Performance (Turbo)

1E-1
1E-2
Performance
1E-3
1E-4
1E-5
1E-6
1E-7
Specification
Turbo 0.495
1E-8
Specification
1E-9
0

Figure 7-4. DMD2050E B/O/QPSK BER Performance (Turbo)

Note: Eb/No values include the effect of using interleaving and maximum iterations.
MN-DMD2050E Revision 2
B/O/QPSK Uncoded Theory
Typical
Turbo 0.793
1 2 3 4
Turbo Decoder
5 6 7 8
Eb/No in dB
