5.3.6 ASYNC (J17)

ASYNC J17
Table 5-5. Pinouts for J17 ASYNC Port 9-pin Female D Connector

5.3.7 ANT. HANDOVER (J18) (Future Option)

MN-DMD2050E Revision 2
Label Description
Asynchronous Data Interface Port
Pin No. Signal Name
1 Receive Data B
2 Receive Data A
3 Transmit Data A
4 Transmit Data B
5 Ground
6 No Connect
7 No Connect
8 No Connect
9 No Connect
Connector Type
9-pin Female D
Signal Direction
RXD_B Output
RXD_A Output
TXD_A Input
TXD_B Input
GND ---
DSR ---
RTS ---
CTS ---
NC ---
External Connections
