ETC Installation Guide
ColorSource PAR v1.5
Note: The ColorSource PAR is not self terminating. You must

Setting up the fixture

1:
2:
3:
Powering up
1:
2:

Adjusting the tilt

The fixture can be tilted up and down and rotated (panned) as needed.
1:
2:
3:

User interface

The user interface allows you to set the start address of the fixture, access the
stand-alone presets and sequences, and set the DMX control mode.
• The DMX address will blink when no DMX is present and a preset or
sequence is not active. The inactivity time-out is disabled while in a
data loss state.
• After 5 seconds of inactivity when DMX is present, the display goes
dark.
ColorSource PAR v1.5
terminate the last fixture in line with a 120 ohm resistor.
XLR terminators are not available from ETC.
To purchase an RJ45 terminator, please contact your
ETC customer service representative and request part
number N4086.
Plug power cord into the powerCON In connector on the rear of the
fixture.
Make any power-thru cable connections prior to applying a power
source.
Plug power cord into power source.
Press the Mode button once to wake the display. The display shows
the DMX address.
Press the Mode button a second time to access the Presets/Sequences
menu.
Loosen, but do not remove the yoke locking knob.
Tilt the fixture to the desired angle.
Tighten the yoke locking knob.
Page 4 of 12 ETC
