Wiring connections

The wiring connections listed below are specific to this firmware.

Main harness (H1), 12-pin black connector

Conn./Pin Color
H1/1 Blue/White
H1/2 Blue/Red
H1/3 Blue
H1/4 White/Brown
H1/5 White
H1/6 Red
H1/7 Lt. Green/Red
H1/8 Lt. Green
H1/9 Lt. Green/White
H1/10 Black
H1/11 White
H1/12 Red

Relay harness (H2), 10-pin white connector

Conn./Pin Color
H2/1 N/A
H2/2
Red/Black
H2/3
Pink/Black
H2/4 Pink/White
H2/5 Red
H2/6 Green
H2/7 Violet
H2/8 Orange
H2/9 Red/White
H2/10 Pink

Data harness (H3), 8-pin white connector

Conn./Pin Color
H3/1 Tan
H3/2 Tan/Black
H3/3 Orange/Brown
H3/4 Orange/Green
H3/5 Lt. Green
H3/6 Violet/Brown
H3/7 Orange/Black
H3/8 Yellow/Black
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
6
Description
Relay 1 N.C. – Immo. Data Interrupt (vehicle side)
Relay 1 N.O. – No Connection
1
Relay 1 COM – Immo. Data Interrupt (connector side)
Relay 3 N.C. – No Connection
1
Relay 3 COM – No Connection
1
(+) 12 Volt (Battery)
Relay 2 N.O. – (-) Ground
1
Relay 2 COM – (-) Clutch Output
Relay 2 N.C. – No Connection
1
(-) Ground
Relay 3 COM – No Connection
1
(+) 12 Volt (Battery)
Description
No Connection
No Connection
No Connection 1
No Connection
1
No Connection
No Connection
1
No Connection
No Connection
1
No Connection
No Connection
Description
HS CAN Low
HS CAN High
No Connection
No Connection
Single Wire CAN
(MUX) Brake Activation Output
No Connection
Immo.Data (connector side)
1
1
1
DS4+ GM9
