Directed DS4+ Installation Manual page 11

Wire Information
Function
Chevrolet Cruze (Smart Key) 2012-2016
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
Clutch Output [3]
Chevrolet Impala (Smart Key) 2014-2016
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
Chevrolet Malibu (Smart Key) 2013-2015
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
11
Color Pin Polarity
Green/Violet 2 Data
Green/Gray 22 (-)
Green 22 Data
Blue 24 Data
White 23 Data
Blue/Yellow 7 MUX
Red/Gray 4 (+)
Yellow B MUX
Green/Violet 2 Data
Green/Gray 22 (-)
Lt. Green 22 Data
Blue 24 Data
White 23 Data
Blue/Yellow 7 MUX
Red/Violet 4 (+)
Green/Violet 2 Data
Gray 22 (-)
Green 22 Data
Blue 24 Data
White 23 Data
Blue 7 MUX
Red/Violet 4 (+)
Connector Information
Location
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
Clutch switch.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
Color Pins Ref.
Green 25 E
White 26 F
Blue 27 G
Blue 27 G
Blue 27 G
Blue 27 G
Blue 27 G
Black 4 D
Green 25 A
White 26 B
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Green 25 A
White 26 B
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
DS4+ GM9
