Directed DS4+ Installation Manual page 10

Wire Information
Function
Buick Regal (Smart Key) 2012-2014
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
Clutch Output [3]
Buick Verano (Smart Key) 2012-2016
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
Clutch Output [3]
Cadillac SRX (Smart Key) 2010-2012
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
Cadillac SRX (Smart Key) 2013-2016
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
Cadillac XTS (Smart Key) 2013-2016
Immo. Data
Parking Lights
SW CAN
HS CAN High
HS CAN Low
Brake
12V
10
Color Pin Polarity
Green/Violet 2 Data
Green/Gray 22 (-)
Green 22 Data
Blue 24 Data
White 23 Data
Blue/Yellow 7 MUX
Red/White or
4 (+)
Red/Brown
Yellow B MUX
Green/Violet 2 Data
Green/Gray 22 (-)
Green 22 Data
Blue 24 Data
White 23 Data
Blue/Yellow 7 MUX
Red/Brown 4 (+)
Yellow B MUX
Green/Violet 2 Data
Green/Brown
22 (-)
or Lt. Green
Lt. Green 22 Data
Dk. Blue 24 Data
Dk. Blue/
23 Data
Yellow
Yellow 7 MUX
Red/Violet 4 (+)
Lt. Green/
2 Data
Violet
Lt. Green/
22 (-)
Gray
Green 22 Data
Tan/Black 24 Data
Tan 23 Data
Blue/Yellow 7 MUX
Red/Violet 4 (+)
Lt. Green/
2 Data
Violet
Lt. Green/
22 (-)
Gray
Lt. Green 22 Data
Lt. Blue 24 Data
White 23 Data
Blue/Yellow 7 MUX
Red/Violet 4 (+)
Connector Information
Location
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
Clutch switch.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
BCM passenger side center console.
Clutch switch.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
BCM under drivers dash.
Color Pins Ref.
Green 25 A
White 26 B
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Black 3 D
Green 25 E
White 26 F
Blue 27 G
Blue 27 G
Blue 27 G
Blue 27 G
Blue 27 G
Black 3 D
Green 25 A
White 26 B
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Green 25 A
B
White 26
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Blue 27 C
Green 25 A
B
White 26
Blue 27 C
C
Blue 27
Blue 27 C
Blue 27 C
Blue 27 C
DS4+ GM9
