Directed DS4+ Installation Manual page 13

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Cadillac ATS (Smart Key) 2013-2015
Immo. Data
Parking Lights
HS CAN High
HS CAN Low
SW CAN
Brake
12V
Clutch Output [3]
Cadillac CTS (Smart Key) 2013-2015
Immo. Data
Parking Lights
HS CAN High
HS CAN Low
SW CAN
Brake
12V
Chevrolet Suburban (Smart Key) 2015
Immo. Data
Parking Lights
HS CAN High
HS CAN Low
SW CAN
Brake
12V
13
Color Pin Polarity
Green/Violet 2 Data
Gray or
22 (-)
Green/Gray
Blue 25 Data
White 24 Data
Green 23 Data
Blue/Yellow 7 MUX
Red/Gray 4 (+)
Yellow B MUX
Green/Violet 2 Data
"Gray or
22 (-)
Green/Gray"
Blue 25 Data
White 24 Data
Green 23 Data
Blue/Yellow 7 MUX
Red/Gray 4 (+)
Green/Violet 2 Data
Green/Gray 22 (-)
Blue 25 Data
White 24 Data
Green 23 Data
White/Green 7 MUX
Red/Violet 4 (+)
Connector Information
Location
BCM behind glove box.
BCM behind glove box.
BCM behind glove box.
BCM behind glove box.
BCM behind glove box.
BCM behind glove box.
BCM behind glove box.
Clutch switch.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
BCM under driver dash.
Color Pins Ref.
Green 25 A
White 26 B
White 26 B
White 26 B
Gray 26 C
Blue 27 D
Blue 27 D
Black 3 E
Green 25 F
White 26 G
White 26 G
White 26 G
Gray 26 H
Blue 27 I
Blue 27 I
Green 25 F
White 26 G
White 26 G
White 26 G
Gray 26 H
I
Blue 27
I
Blue 27
DS4+ GM9
