Technical data, mains supply 3 x 380 - 480 V

According to international
standards
Output current
(3 x 380-480V)
Output power (400
V)
Typical shaft output
Typical shaft output
Max. cable cross
section, motor
Input current
(3 x 380-480 V)
Max. cable cross
section, power
Max. pre-fuses
3)
Efficiency
Power loss at max.
load
Weight
* At mains voltage min 3 x 460 - 480 V
** t max. 35° C.
amb
1. American Wire Gauge. Max. cable cross
section is the largest cable cross section that can
be attached to the terminals. Always observe
national and local regulations.
2. Typr gG / gL pre fuses or corrosponding
circuit brakers should be used.
If you want to maintain UL/cUL branch circuit fuses
according to NEC should be used. Alternati v ely
a circuit braker Danfoss type CTI 25 MB or
equi v alent should be used.
To be placed for protection in a circuit that is
capable of supplying a maximum of 100,000 amps
for fuses / 10,000 amps for circuit brakers.
3. Measured using a 10 m screened/armoured
motor cable with a rated load and rated frequency.
116
Type 303 305
I [A] 1.4 1.8
INV.
I (60s) [A] 2.2 2.9
MAX
S [KVA] 1.0 1.2
INV.
P [kW] 0.37 0.55
M,N
P [HP] 0.50 0.75
M,N
2 1)
[mm /AWG] 4/10 4/10
I [A] 1.2 1.6
L,N
I (60s)[A] 1.9 2.6
L,MAX
2 1)
[mm /AWG] 4/10 4/10
2)
[IEC]/UL [A] 25/25 25/25
[%] 96
[W] 22 29
[kg] 5.8 5.8
®
VLT FCD Series
307 311 315
2.2 3.0 3.7
3.5 4.8 5.9
1.5 2.0 2.6
0.75 1.1 1.5
1.0 1.5 2.0
4/10 4/10 4/10
1.9 2.6 3.2
3.0 4.2 5.1
4/10 4/10 4/10
25/25 25/25 25/25 25/25
40 59 80
5.8 5.8 5.8
MG.04.B7.02 - VLT is a registered Danfoss trademark
322 330 335**
5.2 7.0 7.6
8.3 11.2 11.4
3.6 4.8 5.3
2.2 3.0 3.3
3.0 4.0 5*
4/10 4/10 4/10
4.7 6.1 6.8
7.5 9.8 10.2
4/10 4/10 4/10
25/25 25/25
117 160 190
9.5 9.5 9.5
