Description of choice:
Set the required maximum output current I
223 Warning: Low current, I
(WARN. CURRENT LO)
Value:
0.0 - par. 224 Warning: High current, I
Function:
If the output current falls below the preset
limit I a warning is gi v en.
LOW
Parameters 223-228 Warning functions are out of
function during ramp-up after a start command and
after a stop command or during stop.The warning
functions are acti v ated when the output frequency
has reached the resulting reference. The signal
outputs can be programmed to gi v e a warning signal
via terminal 46 and via the relay output.
Description of choice:
The lower signal limit of the output current I
must be programmed within the normal working
range of the frequency converter.
224 Warning: High current, I
(WARN. CURRENT HI)
Value:
0 - I
MAX
Function:
If the output current exceeds the preset limit
I a warning is gi v en.
HIGH
Parameters 223-228 Warning functions do not
work during ramp-up after a start command and
after stop command or during stop. The warning
functions are acti v ated when the output frequency
has reached the resulting reference. The signal
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.B7.02 - VLT is a registered Danfoss trademark
.
LIM
LOW
0.0 A
HIGH
LOW
HIGH
I
MAX
®
VLT FCD Series
outputs can be programmed to gi v e a warning signal
via terminal 46 and via the relay output.
Description of choice:
The output current's upper signal limit I
be programmed within the frequency converter's
normal operating range. See drawing at parameter
223 Warning: Low current, I
225 Warning: Low frequency, f
(WARN.FREQ. LOW)
Value:
0.0 - par. 226
Warn.: High frequency, f
Function:
If the output frequency falls below the preset
limit f , a warning is gi v en.
LOW
Parameters 223-228 Warning functions are out of
function during ramp-up after a start command and
after stop command or during stop. The warning
functions are acti v ated when the output frequency
has reached the resulting reference. The signal
outputs can be programmed to gi v e a warning signal
via terminal 46 and via the relay output.
Description of choice:
The lower signal limit of the output frequency f
must be programmed within the normal operating
range of the frequency converter. See drawing at
parameter 223 Warning: Low current, I
226 Warning: High frequency f
(WARN.FREQ.HIGH)
Value:
Par. 200 Frequency range = 0-132 Hz [0]/[1].
par. 225 f - 132 Hz
LOW
Par. 200 Frequency range = 0-1000 Hz [2]/[3].
par. 225 f - 1000 Hz
LOW
Function:
If the output frequency exceeds the preset
limit f a warning is gi v en.
HIGH
Parameters 223-228 Warning functions do not
work during ramp-up after a start command and
after stop command or during stop. The warning
functions are acti v ated when the output frequency
has reached the resulting reference. The signal
must
HIGH
.
LOW
LOW
0.0 Hz
HIGH
LOW
.
LOW
HIGH
132.0 Hz
132.0 Hz
