Danfoss VLT FCD 303 Operating Instructions Manual page 121

Factory settings
PNU # Parameter
description
302 Digital input, term. 18
303 Digital input, term. 19
304 Digital input, term. 27
305 Digital input, term. 29
307 Digital input, term. 33
308 Term. 53, analogue input voltage
309 Term. 53, min scaling
310 Term. 53, max scaling
314 Term. 60, analogue input current
315 Term. 60, min scaling
316 Term. 60, max scaling
317 Time out
318 Function after timeout
319 Term. 42, analogue output
323 Relay output
327 Pulse Max. 33
328 Pulse Max. 29
341 Term. 46 digital output
342 Term. 46 Max. pulse output
343 Precise stop function
344 Counter value
349 Speed comp delay
MG.04.B7.02 - VLT is a registered Danfoss trademark
Factory setting Changes
during
operation
Start Yes
Reversing Yes
Reset and coast inverse Yes
Jog Yes
No function Yes
Reference Yes
0.0 V Yes
10.0 V Yes
No function Yes
0.0 mA Yes
20.0 mA Yes
10 sec. Yes
No function Yes
0-I = 0-20 mA Yes
MAX
No function Yes
5000 Hz Yes
5000 Hz Yes
No function Yes
5000 Hz Yes
Normal ramp stop No
100000 pulses No
10 ms Yes
®
VLT FCD Series
4-setup Conv.
index
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes -1
Yes -1
Yes 0
Yes -4
Yes -4
Yes -1
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes 0
Yes -3
Data
type
5
5
5
5
5
5
6
6
5
6
6
5
5
5
5
7
7
5
6
5
7
6
121
