Technical functions

600-605 Operating Data
Value:
Par. no. Description
600 Operating hours
601 Hours run
602 kWh counter
603 Number of power-up's
604 Number of overtemperatures
605 Number of overvoltages
Function:
These parameters can be read out via the serial
communication port and the LCP control unit.
Description of choice:
Parameter 600, Operating hours:
Gi v es the number of hours the frequency
converter has been operating. The value is
saved every hour and when there is a mains
failure. This value cannot be reset.
Parameter 601, Hours run:
Gi v es the number of hours the motor has been
operating since the reset in parameter 619 Reset
of hours-run counter. The value is saved every
hour and when there is a mains failure.
Parameter 602, kWh counter:
Gi v es the frequency converter's output energy in
kWh. The calculation is based on the mean kW
value over one hour. This value can be reset using
parameter 618 Reset of kWh counter.
Range: 0 - depends on unit.
Parameter 603, Number of power-ups:
Gi v es the number of power-ups of the supply voltage
undertaken on the frequency converter.
Parameter 604, Number of overtemperatures:
Gi v es the number of overtemperature faults that have
been registered on the frequency converter's heat sink.
Parameter 605, Number of overvoltages:
Gi v es the number of overvoltages of the intermediate
circuit voltage in the frequency converter. This is only
counted when Alarm 7 Overvoltage is acti v e.
NB!:
Parameters 615-617 Fault log cannot be read
out via the integral control unit.
= factory setting. () = display text [] = value for use in communication via serial communication port
96
Display text
(OPERATING HOURS)
(RUNNING HOURS)
(KWH COUNTER)
(POWER UP'S)
(OVER TEMP'S)
(OVER VOLT'S)
615 Fault log: Error code
Value:
[Index 1 - 10] Error code: 0 - 99
Function:
In this parameter it is possible to see the reason for
a trip (cut-out of the frequency converter) occurring.
10 [1-10] log values are defined.
The lowest log number [1] contains the latest/most
recently saved data value. The highest log number
[10] contains the oldest data value saved. If a trip
occurs, it is possible to see the cause, time and a
possible value of the output current or output voltage.
Description of choice:
Gi v en as a fault code, in which the number refers to a
table. See the table in Warnings/alarm messages.
616 Fault log: Time
Value:
[Index 1 - 10] Hours: 0 - 130,000.0
Function:
In this parameter it is possible to see the total number
of operating hours in connection with the last 10 trips.
10 [1-10] log values are denoted. The lowest
log number [1] contains the latest/most recently
saved data value, and the highest log number
[10] contains the oldest data value.
Description of choice:
Read out as one value.
MG.04.B7.02 - VLT is a registered Danfoss trademark
®
VLT FCD Series
Unit
Hours
Hours
kWh
Number of times
Number of times
Number of times
(F.LOG: ERROR COD)
(F.LOG: TIME)
Range
0-130,000.0
0-130,000.0
Depends on unit
0-9999
0-9999
0-9999
