OneTouch AT 10G
User Manual
Gateway Test
Description
Tap the gateway icon to identify the IP and MAC addresses of the
current IPv4 and IPv6 router. Routing protocols and router ping
connectivity are also reported. If SNMP is enabled, parameters
such as name, location, description, contact and up time as well as
router errors and discards are displayed.
Configuration
To display System Group information and Statistics, they must be
available on the network via SNMP and you must configure the
analyzer for SNMP. See "SNMP" on
How it Works
The analyzer gets the IP address of the gateway via DHCP or static
configuration. Then the analyzer attempts to elicit a response
from the gateway.
The analyzer uses SNMP to acquire system group information and
statistics for the port that services the analyzer's subnet.
Information in the Advertisement section of the RESULTS screen is
gathered in a variety of ways, including via IPv6 router
advertisements.
74
page 146.
