Multiport Statistics Details Screen - Netscout OneTouch AT 10G User Manual

MultiPort Statistics Port Details Screen
Tap a port's button to expand it and view its details.
Problem
summary
Current
value
Ports
linked (up)
and
idle (down)
Sort
controls
Figure 62. MultiPort Statistics Details Screen
Warning Triangle
out) utilization is 70% or more, or when discards or errors occur.
Thresholds - The utilization bars and lines turn yellow at 40%; red
at 70%. Discard error bars and lines are always shown in red.
Devices button - This button will only be shown if any attached
devices are detected on the selected port. Selecting this button
will show a listing of all the attached devices.
MultiPort Statistics Devices on Port Details Screen
Selecting the Devices button will show a listing of all attached
devices on the current port. If you select a device that is SNMP
- The warning triangle appears when (in or
Chapter 7: Wired Analysis
Triangle
indicates
an error
or warning
Number of
attached
devices
Total
since
MultiPort
statistics
began
Maximum
value
observed
Button
shows only
if any at-
tached de-
vices are
detected
167
