INDICATOR TROUBLESHOOTING TABLE

The following is a troubleshooting table for the AED indicators.
VIEW SYMPTOM
Red SERVICE indicator (LED)
is lit.
Red PADS indicator (LED) is lit.
The last battery indicator (LED)
is red.
STATUS INDICATOR is RED,
(for Powerheart AED only) and
no other indicators on the
diagnostic panel are lit.
CAUTION: Temperature Extremes
Exposing the AED to extreme environmental conditions outside of its operating parameters may
compromise the ability of the AED to function properly. The RescueReady
impact of extreme environmental conditions on the AED. If the daily self-test determines environmental
conditions outside of the AED's operating parameters, a "SERVICE REQUIRED" alert will be issued
to prompt the user to move the AED to environmental conditions within the acceptable operating
parameters at once. See Section 7 – Technical Data, Parameters, Operation and Standby Conditions
on page 48.
page 42
SOLUTION
Maintenance by authorized service personnel is required.
Call Cardiac Science Customer Service (see page 4) or
your local Cardiac Science distributor.
Connect the pads or replace with a new pair.
The battery is low. Replace with a new battery.
The battery power is completely depleted. Replace with
a new battery. If STATUS INDICATOR remains RED, refer
to the Powerheart AED for maintenance.
Call Cardiac Science Customer Service or your local
Cardiac Science distributor.
112-2025-005 Rev B
® daily self-test verifies the
