PADS

An audible alert for the FirstSave AED will be heard after the self-test if the pads are missing or unplugged.
On the Powerheart AED, an audible and visual alert will indicate after the self-test if the pads are missing,
unplugged or damaged.
CAUTION: Possible Improper AED Performance
Using pads that are damaged or expired may result in improper AED performance.
PAD INSTALLATION
1. Open the lid of the AED.
2. Place the pad package into the lid so that the expiration label is visible through the
clear window on the lid. The expiration date of the pads will then be readable
without opening the lid of the AED.
3. Match the color of the connectors (red to red), then plug the pad connector into the
AED case as shown in the drawing.
4. Tuck the excess cable length in the bottom holder as shown in the drawing. With the
pad package completely secured to the AED lid, close the lid.
5. Make sure the expiration date is visible through the clear window of the lid
a. For the Powerheart AED, check to make sure that the STATUS INDICATOR is GREEN .
OR
b. For the FirstSave AED, open the lid and check to make sure the pad indicator
LED is not lit. If the pads are not installed properly, the PAD indicator will
illuminate; call Customer Service for assistance.
CAUTION: Use only Cardiac Science Approved Equipment
Using batteries, pads, cables, or optional equipment other than those approved by
Cardiac Science may cause the AED to function improperly during a rescue.
CAUTION: Possible Improper AED Performance
Using pads that are damaged or expired may result in improper AED performance.
page 26
The defibrillation pads come in a ready-to-use, sealed package containing
one pair of self-adhesive pads with an attached cable and connector. The
pads are disposable and should be discarded after each rescue.
The pads have a limited shelf life and should not be used beyond the
expiration date. Keep a fresh, unopened pair of pads plugged into the AED
at all times. Refer to the pad package label for operation temperatures.
