Electrical diagrams
2920 7090 51
Electric cabinet
Description
Fuses
Fuses
Overload relay, compressor motor
Delta contactor
Star contactor
Line contactor
Transformer
Earth terminal
The service diagram and the explanatory designations below are given as typical example
only. Some of the texts may not be applicable to a specific case.
The applicable service diagram is situated in the electric cubicle of the compressor.
