- Page 1 Atlas Copco Oil-injected rotary screw compressors GA 5 VSD MED, GA 7 VSD MED, GA 11 VSD MED, GA 15 VSD MED Medical Instruction book...
- Page 3 Atlas Copco Oil-injected rotary screw compressors GA 5 VSD MED, GA 7 VSD MED, GA 11 VSD MED, GA 15 VSD MED Medical From following serial No. onwards: CAI 708 272 Instruction book Original instructions Copyright notice Any unauthorized use or copying of the contents or any part thereof is prohibited.
-
Page 4: Table Of Contents
Instruction book Table of contents Safety precautions......................5 ...........................5 AFETY ICONS ......................5 AFETY PRECAUTIONS GENERAL ...................6 AFETY PRECAUTIONS DURING INSTALLATION ....................7 AFETY PRECAUTIONS DURING OPERATION ................8 AFETY PRECAUTIONS DURING MAINTENANCE OR REPAIR General description......................10 ..........................10 NTRODUCTION ............................11 IR FLOW ............................12 IL FLOW ..........................13 OOLING SYSTEM ........................14... - Page 5 Instruction book 3.10 .......................38 MERGENCY FORCED LOCAL 3.11 ..........................39 ERVICE MENU 3.12 ........................43 ODIFYING THE SETPOINT 3.13 ........................45 VENT HISTORY MENU 3.14 ......................46 ODIFYING GENERAL SETTINGS 3.15 ............................48 NFO MENU 3.16 .............................49 EST MENU 3.17 ........................50 SER PASSWORD MENU 3.18 ..........................51 EB SERVER 3.19...
- Page 6 Instruction book ..........................77 ERVICE KITS ......................77 ISPOSAL OF USED MATERIAL Adjustments and servicing procedures..............78 ..........................78 RIVE MOTOR ............................78 IR FILTER .......................79 IL AND OIL FILTER CHANGE ........................80 IL SEPARATOR CHANGE ............................81 OOLERS ....................81 ELT TENSIONING AND REPLACEMENT ..........................83 AFETY VALVES Problem solving......................85 Technical data.......................88 ........................88...
-
Page 7: Safety Precautions
Instruction book Safety precautions Safety icons Explanation Danger for life Warning Important note Safety precautions, general General precautions 1. The operator must employ safe working practices and observe all related work safety requirements and regulations. 2. If any of the following statements does not comply with the applicable legislation, the stricter of the two shall apply. -
Page 8: Safety Precautions During Installation
Instruction book Safety precautions during installation All responsibility for any damage or injury resulting from neglecting these precautions, or non observance of the normal caution and care required for installation, operation, maintenance and repair, even if not expressly stated, will be disclaimed by the manufacturer. -
Page 9: Safety Precautions During Operation
Instruction book 18. If the ground is not level or can be subject to variable inclination, consult the manufacturer. Also consult following safety precautions: Safety precautions during operation Safety precautions during maintenance. These precautions apply to machinery processing or consuming air or inert gas. Processing of any other gas requires additional safety precautions typical to the application which are not included herein. -
Page 10: Safety Precautions During Maintenance Or Repair
Instruction book Also consult following safety precautions: Safety precautions during installation Safety precautions during maintenance. These precautions apply to machinery processing or consuming air or inert gas. Processing of any other gas requires additional safety precautions typical to the application which are not included herein. - Page 11 Instruction book 18. Protect the motor, air filter, electrical and regulating components, etc. to prevent moisture from entering them, e.g. when steam cleaning. 19. Make sure that all sound-damping material and vibration dampers, e.g. damping material on the bodywork and in the air inlet and outlet systems of the compressor, is in good condition. If damaged, replace it by genuine material from the manufacturer to prevent the sound pressure level from increasing.
-
Page 12: General Description
General description Introduction GA 5 VSD MED up to GA 15 VSD MED are single-stage, oil-injected screw compressors driven by an electric motor. The compressors are air-cooled. The motor is powered by a frequency converter, allowing to adapt the speed to the air demand for optimal power consumption. -
Page 13: Air Flow
Instruction book Reference Name Function Elektronikon® controller See sections Elektronikon Graphic controller - General and further. Emergency stop button To stop the unit in case of emergency Mains switch To switch off the power to the compressor. Ammeter Indicates the compressor current. Hand / Auto (Local / LAN) switch In the Auto (LAN) position, the pump will be controlled by the ES MED. -
Page 14: Oil Flow
Instruction book Description Air drawn through filter (AF) and open inlet valve (IV) into compressor element (E) is compressed. Compressed air and oil flow into the oil tank (OT). The air is discharged through outlet valve (AV) via minimum pressure valve (Vp) and air cooler (Ca). During loaded operation, minimum pressure valve (Vp) keeps the pressure in the separator tank (OT) above a minimum value, required for lubrication. -
Page 15: Cooling System
Instruction book serves as oil tank. The remaining oil is removed by oil separator (OS). A small pipe returns the separated oil towards the compressor element. Air pressure forces the oil from oil separator/tank through oil cooler (Co) and oil filter (OF) towards compressor element (E). -
Page 16: Condensate System
Instruction book Condensate system Condensate drains Condensate drain connections The compressors have a condensate trap (MT) downstream the air cooler. The condensate trap is provided with a manual drain outlet (Dm) and an automatic drain outlet (Da). Regulating system Unloading valve assembly (loaded condition) Description If the consumption is less than the air output of the compressor, the net pressure increases. -
Page 17: Electrical System
Instruction book • Unloading valve (UV) is opened by the pressure in the oil separator vessel. The pressure from the oil separator vessel is released into atmosphere through the unloader (UA). • The pressure in the oil separator vessel stabilises at low value. A reduced amount of air is compressed to guarantee a minimal pressure, required for lubrication during unloaded operation. -
Page 18: Electrical Diagram
Instruction book Reference Description F1/2/3/4 Fuses Line contactor Earth terminal Elektronikon controller Emergency stop button Fan motor contactor Fan motor circuit breaker Frequency converter CAN bus connector SSA/SSB Service switch External box Reference Description Fuses Earth terminal Main switch Local / LAN switch Ammeter Electrical diagram The complete electrical diagram can be found in the electric cubicle. - Page 19 Instruction book Specific components Pressure switch on oil separator vessel This switch, referred to as FTGOL (Failed To Go On Load), gives feedback to the regulation system that pressure is built up in the vessel when the compressor is loaded. It is a normally open switch, and it closes when the pressure is above 2-3 bar.
-
Page 20: Air Receiver
Instruction book This sensor measures the temperature of the compressed air after the cooler. It gives a warning when the temperature exceeds 55°C, since this is not optimal for the dryer down the line. Ammeter The Ammeter in the cubicle door measures the current and allows to follow up unusual behaviour. Main switch The main switch allows to cut the power supply to the cubicle, during maintenance or during problem solving. -
Page 21: Elektronikon® Graphic Controller
Instruction book Elektronikon® Graphic controller General Control panel ® Display of the Elektronikon Graphic controller Introduction The Elektronikon controller has following functions: • Controlling the compressor • Protecting the compressor • Monitoring components subject to service • Automatic restart after voltage failure Automatic control of the compressor operation The regulator maintains the net pressure between programmable limits by automatically loading and unloading the compressor. -
Page 22: Automatic Restart After Voltage Failure
The regulator has a built-in function to automatically restart the compressor if the voltage is restored after voltage failure. This function is activated. If desired, the function can be deactivated. Consult Atlas Copco. If activated and provided the regulator was in the automatic operation mode, the... -
Page 23: Control Panel
Instruction book Control panel Elektronikon regulator Control panel Parts and functions Reference Designation Function Display Shows the compressor operating condition and a number of icons to navigate through the menu. Pictograph Automatic operation Pictograph General alarm General alarm LED Flashes if a shut-down warning condition exists. Pictograph Service Service LED... -
Page 24: Icons Used
Instruction book Icons used Status icons Name Icon Description Stopped / Running When the compressor is stopped, the icon stands still. When the compressor is running, the icon is rotating. Compressor status Motor stopped Running unloaded Running loaded Machine control mode Local start / stop Remote start / stop Network control... - Page 25 Instruction book Active protection functions Emergency stop Shutdown Warning Service Service required Main screen display Value lines display icon Chart display icon General icons No communication / network problem Not valid Input icons Icon Description Pressure Temperature Digital input Special protection System icons Icon Description...
- Page 26 Instruction book Compressor element (LP, HP, ...) Dryer Frequency converter Drain Filter Motor Failure expansion module Network problem General alarm Specific icons on ES MED Icon Description Temperature element outlet Temperature compressor outlet Failed to go load: no pressure (>3bar) detected while compressor is loaded Motor overload: motor draws too much current No answer: compressor doesn’t respond to ES commands Menu icons...
- Page 27 Instruction book Inputs Outputs Alarms (Warnings, shutdowns) Counters Test Settings Service Event history (saved data) Access key / User password Network Setpoint Info Navigation arrows Icon Description Down 2920 7104 10...
-
Page 28: Main Screen
Instruction book Main screen Control panel Scroll keys Enter key Escape key Function The Main screen is the screen that is shown automatically when the voltage is switched on and one of the keys is pushed. It is switched off automatically after a few minutes when no keys are pushed. Typically, 4 different main screen views can be chosen: 1. - Page 29 Instruction book Typical Main screen (4 value lines), GA MED with frequency converter Text on images Compressor Outlet Flow (compressors with frequency converter) Off, Load, Shutdown,... (text varies upon the compressors actual condition) Menu Running hours • Section A shows information regarding the compressor operation (e.g. the outlet pressure or the temperature at the compressor outlet).
- Page 30 Instruction book To activate an action button, highlight the button by using the Scroll keys and press the Enter key. To go back to the previous menu, press the Escape key. Chart views Instead of viewing values, it is also possible to view a graph of one of the input signals (see section Inputs menu) in function of the time.
- Page 31 Instruction book When the Chart (Low Resolution) is selected, the chart shows the variation of the selected input per day. The screen shows the evolution over the last 10 days. Selection of a main screen view To change between the different screen layouts, select the far right icon in the control icons line (see value lines display icon or chart display icon in section Icons used) and press the Enter key.
-
Page 32: Calling Up Menus
Instruction book Calling up menus Control panel Control panel Scroll keys Enter key Escape key Description When the voltage is switched on, the main screen is shown automatically (see section Main screen): Typical Main screen (2 value lines), fixed speed compressors 2920 7104 10... - Page 33 Instruction book Typical Main screen (2 value lines), compressors with frequency converter Typical Main screen (4 value lines), GA MED with frequency converter • To go to the Menu screen, highlight the Menu button (3), using the Scroll keys. • Press the Enter key to select the menu. Following screen appears: •...
-
Page 34: Inputs Menu
Instruction book Inputs menu Control panel Scroll keys Enter key Escape key Menu icon, Inputs Function • To display the actual value of the measured data (analog inputs) and the status of the digital inputs (e.g. emergency stop contact, motor overload relay, etc.). •... - Page 35 Instruction book Menu Regulation • Using the Scroll keys, move the cursor to the Inputs icon (see above, section Menu icon). • Press the Enter key. A screen similar to the one below appears: Text on image Inputs Compressor outlet Element outlet Ambient air Emergency stop...
- Page 36 Instruction book Press Enter again to remove this input from the chart. Another confirmation pop-up opens: Select Yes to remove or No to quit the current action. In a similar way, another input signal can be highlighted and selected as Main Chart signal: (1): Set as main chart signal 2920 7104 10...
-
Page 37: Outputs Menu
Instruction book Outputs menu Control panel Scroll keys Enter key Escape key Menu icon, Outputs Function To call up information regarding the actual status of some outputs such as the condition of the Fan overload contact (on air cooled compressors), the Emergency stop contact, etc. Procedure Starting from the Main screen (see Main... -
Page 38: Counters
Instruction book Menu Regulation • Move the cursor to the Outputs icon (see above, section Menu icon, using the Scroll keys. • Press the Enter key. A screen similar to the one below appears: Outputs screen (typical) Text on figure Outputs Fan motor contact Blow-off contact... - Page 39 Instruction book Scroll keys Enter key Escape key Menu icon, Counters Function To call up: • The running hours • The loaded hours • The number of motor starts • The number of hours that the regulator has been powered •...
-
Page 40: Lan Or Local Control
Instruction book Counters Running hours Motor starts Load relay VSD 1-20 % rpm in % (the percentage of the time during which the motor speed was between 1 and 20 %) (compressors with frequency converter) The screen shows a list of all counters with their actual readings. Note: the example above is for a frequency converter driven compressor. -
Page 41: Service Menu
Instruction book 3.11 Service menu Control panel Scroll keys Enter key Escape key 2920 7104 10... - Page 42 Instruction book Menu icon, Service Function • To reset the service plans which are carried out. • To check when the next service plans are to be carried out. • To find out which service plans were carried out in the past. •...
- Page 43 Instruction book Overview Text on figure Overview Running Hours (green) Real Time hours (blue) Reset Example for service level (A): The figures at the left are the programmed service intervals. For Service interval A, the programmed number of running hours is 4000 hours (upper row, green) and the programmed number of real time hours is 8760 hours, which corresponds to one year (second row, blue).
- Page 44 Instruction book Service plan Level Running hours Real time hours Modify Modifying a service plan Dependant on the operating conditions, it can be necessary to modify the service intervals. To do so, use the Scroll keys to select the value to be modified. A screen similar to the one below appears: Press the Enter key.
-
Page 45: Modifying The Setpoint
Instruction book Next service Level Running hours Actual In the example above, the A Service level is programmed at 4000 running hours, of which 0 hours have passed. History The History screen shows a list of all service actions done in the past, sorted by date. The date at the top is the most recent service action. - Page 46 Instruction book Procedure Starting from the Main screen (see Main screen), • Highlight the action key Menu using the Scroll keys and press the Enter key. Following screen appears: Text on figure Menu Regulation • Activate the menu by pressing the enter key. A screen similar to the one below appears: Text on figure Regulation Setpoint 1...
-
Page 47: Event History Menu
Instruction book • The first line of the screen is highlighted in red. Use the Scroll keys (1) to highlight the setting to be modified and press the Enter key (2). Following screen appears: The upper and lower limit of the setting is shown in grey, the actual setting is shown in black. Use the ↑ or ↓... -
Page 48: Modifying General Settings
Instruction book Menu icon, Event History Function To call up the last shut-down and last emergency stop data. Procedure Starting from the Main screen (see Main screen), • Move the cursor to the action button Menu and press the Enter key. Following screen appears: •... - Page 49 Instruction book Scroll keys Enter key Escape key Menu icon, Settings Function To display and modify a number of general settings (e.g. Time, Date, Date format, Language, units ...) Procedure Starting from the Main screen (see Main screen), • Move the cursor to the action button Menu and press the Enter key. Following screen appears: •...
-
Page 50: Info Menu
Scroll keys Enter key Escape key Menu icon, Info Function To show the Atlas Copco internet address. Procedure Starting from the Main screen (see Main screen), • Move the cursor to the action button Menu and press the Enter key. Following screen appears:... -
Page 51: Test Menu
Instruction book • Using the Scroll keys, move the cursor to the Info icon (see above, section Menu icon). • Press the Enter key. The Atlas Copco internet address appears on the screen. 3.16 Test menu Control panel Menu icon, Test Function •... -
Page 52: User Password Menu
Instruction book • The safety valve test can only be performed by authorized personnel and is protected by a security code. • Select the item display test and press the enter key. A screen is shown to inspect the display, at the same time all LED's are lit. -
Page 53: Web Server
Instruction book • Move the cursor to the action button Menu and press the Enter key. Following screen appears: • Using the Scroll keys, move the cursor to the Password icon (see above, section Menu icon) • Press the Enter key. •... - Page 54 Instruction book Configuration of the network card • Go to My Network places (1). • Click on View Network connections (1). • Select the Local Area connection (1), which is connected to the controller. 2920 7104 10...
- Page 55 Instruction book • Click with the right button and select properties (1). • Use the checkbox Internet Protocol (TCP/IP) (1) (see picture). To avoid conflicts, de-select other properties if they are selected. After selecting TCP/IP, click on the Properties button (2) to change the settings. •...
- Page 56 Instruction book • When using Internet Explorer: Open Internet Explorer and click on Tools - Internet options (2). • Click on the Connections tab (1) and then click on the LAN settings button (2). • In the Proxy server Group box, click on the Advanced button (1). 2920 7104 10...
- Page 57 Instruction book • In the Exceptions Group box, enter the IP address of your controller. Multiple IP addresses can be given but they must be separated with semicolons (;). Example: Suppose that you already added two IP addresses (192.168.100.1 and 192.168.100.2). Now you add 192.168.100.100 and separate the 3 IP addresses by putting semicolons between them (1) (see picture).
- Page 58 Instruction book Navigation and options • The banner shows the compressor type and the language selector. In this example, three languages are installed on the controller. • On the left side of the interface you can find the navigation menu (see picture below). If a license for ESi is foreseen, the menu contains 3 buttons.
- Page 59 Instruction book Compressor settings All compressor settings can be hidden or shown. Put a mark for each setting. Only the machine status is fixed and can not be removed from the main screen. Analog inputs (The units of measure can be changed in the preference button from the navigation menu). Counters Counters give an overview of all actual counters from controller and compressor.
-
Page 60: Cascading Load Cut-In Values In Local Mode
Instruction book Digital outputs Shows a list of all digital outputs and their status. Special protections Give an overview of all special protections of the compressor. Service plan Shows all levels of the service plan and status. This screen only shows the running hours. It is also possible to show the actual status of the service interval. -
Page 61: Programmable Settings
Instruction book Load = Unload - ((n + 1 - x) * Band /n), with n = number of compressors x = CAN address Band = Unload – Load 3.20 Programmable settings Compressor/motor Minimum Factory Maximum setting setting setting Set-point 1 and 2 bar(e) Set-point 1 and 2 psig... - Page 62 The built-in service timers will give a Service warning message after their respective preprogrammed time interval has elapsed. Also see section Preventive maintenance schedule.. Consult Atlas Copco if a timer setting has to be changed. The intervals must not exceed the nominal intervals and must coincide logically. See section Modifying general settings.
-
Page 63: Installation
Instruction book Installation Dimension drawings 2920 7104 10... -
Page 64: Installation Proposal
Instruction book Installation proposal 2920 7104 10... - Page 65 Instruction book Description Install the compressor unit on a solid, level floor suitable for taking the weight. Recommended minimum distance between top of the unit and ceiling is 900 mm (35 in). Stated distances between unit and walls are minimum. * Recommended distance is 500 mm for easy access.
-
Page 66: Electrical Connections
• Manual load/unload or automatic operation (K07) • Warning condition (K08) • Shut-down condition (K05) Maximum contact load: 10 A / 250 V AC. Stop the compressor and switch off the voltage before connecting external equipment. Consult Atlas Copco. 2920 7104 10... -
Page 67: Pictographs
Instruction book Pictographs Explanation of pictographs Reference Designation Switch off the voltage and depressurize the compressor before starting maintenance or repairs Keep the doors closed during operation Switch off the voltage before removing protecting cover inside electric cubicle Manual condensate drain Automatic condensate drain Stop the compressor before cleaning the coolers Lightly oil the gasket of the oil filter, screw the filter on and tighten by hand (approx. -
Page 68: Operating Instructions
Instruction book Operating instructions Initial start-up Safety The operator must apply all relevant Safety precautions. Procedure For the location of the air outlet valve and the drain connections, see sections Introduction Condensate system. Position of oil sight glass Consult the sections Cable size and fuses, Installation proposal... - Page 69 Provide labels, warning the operator that: • The compressor may automatically restart after voltage failure (if activated, consult Atlas Copco). The compressor is automatically controlled and may be restarted automatically. • Affix the above sheet, explaining the procedure for checking the motor rotation direction, to the cooling air outlet of the compressor.
-
Page 70: Starting
Instruction book Starting Procedure For the position of the air outlet valve and the drain connections, see sections Introduction Condensate system. Before starting, always check the oil level. Top up as necessary. Control panel Elektronikon® Graphic Step Action Open the air outlet valve. Check that the local/LAN switch is in local position Switch on the voltage. -
Page 71: During Operation
Instruction book During operation Warnings The operator must apply all relevant Safety precautions. Also consult section Problem solving. If the compressor is stopped because the supply voltage is interrupted, please be aware that it will restart automatically when the power is restored! When the motors are stopped and LED (8) (automatic operation) is alight, the motors may start automatically. - Page 72 Instruction book Checking the oil level Control panel Elektronikon® Graphic Regularly check the oil level. To do this, switch the Local/LAN switch to Local and press the stop button (9). Three minutes after stopping, sight-glass (Gl) should be between 1/4 and 3/4 full. Unless the Slave unit (in this case the GA MED compressor) is put in Isolated mode on the ES-MED (see dryer instruction book), a plant fault will be transmitted.
-
Page 73: Checking The Display
Instruction book Air filter Especially if the compressor is installed in a dusty environment, inspect the air filter element regularly. Replace when necessary. See also section Air filter and section Maintenance schedule for periodic replacement instructions. Drains Regularly check that condensate is discharged during operation. See section Condensate system . -
Page 74: Stopping
Instruction book Stopping Elektronikon regulator Control panel Elektronikon® Graphic Procedure Step Action Switch the Local/LAN switch to Local. Press stop button (9). Automatic operation LED (8) goes out and the compressor stops after 30 seconds of unloaded operation. To stop the compressor in the event of an emergency, press emergency stop button (10). - Page 75 Instruction book Procedure Step Action Stop the compressor and close the air outlet valve. Open the manual condensate drain. Consult section Condensate system to locate the drain valve. Switch off the voltage and disconnect the compressor from the mains. Unscrew the oil filler plug only one turn to permit any pressure in the system to escape. Consult section Oil and oil filter change to locate the filler plug.
-
Page 76: Maintenance
Instruction book Maintenance Preventive maintenance schedule Control panel Control panel Elektronikon® Graphic Warning The Medical Air Plant installations require periodic routine maintenance to ensure trouble free and reliable operation throughout the life of the Plant. All maintenance work must be carried out by a competent person who must be fully conversant with the procedures and standards required when working on medical Air systems. - Page 77 Tools and equipment (Medical Air Plant) A full service and complete maintenance engineers standard tool kit is required to service a Atlas Copco Medical Air Plant. During use, there is a possibility that tools will become contaminated with oil or grease, it is therefore important that tools are cleaned and degreased following any maintenance operation, especially if the same tools are subsequently used with an Oxygen system.
-
Page 78: Oil Specifications
Oil specifications It is strongly recommended to use genuine Atlas Copco Lubricants. They are the result of years of field experience and research. See section Preventive maintenance schedule for the advised replacement intervals and consult your Spare Parts list for part number information. -
Page 79: Storage After Installation
Service kits For overhauling and for preventive maintenance, a wide range of service kits is available. Service kits comprise all parts required for servicing the component and offer the benefits of genuine Atlas Copco parts while keeping the maintenance budget low. -
Page 80: Adjustments And Servicing Procedures
Instruction book Adjustments and servicing procedures Drive motor General Keep the outside of the electric motor clean for efficient cooling. If necessary, remove dust with a brush and/ or compressed air jet. Bearing maintenance The motor bearings do not need to be regreased during their normal service life. Air filter Location of air filter Air filter... -
Page 81: Oil And Oil Filter Change
Instruction book Oil and oil filter change Warning The operator must apply all relevant Safety precautions. Always drain the compressor oil at all drain points. Used oil left in the compressor can contaminate the oil system and can shorten the lifetime of the new oil. Never mix lubricants of different brands or types as they may not be compatible and the oil mix will have inferior properties. -
Page 82: Oil Separator Change
Instruction book 7. Depressurise the system by unscrewing filler plug (FC) just one turn to permit any pressure in the system to escape. Remove the plug. Add oil until the sight-glass (Gl) is 3/4 full. Take care that no dirt enters the system. Tighten the filler plug. 8. -
Page 83: Coolers
• Next, clean with an air jet in the reverse direction to normal flow. Use low pressure air. If necessary, the pressure may be increased up to 6 bar(e) (87 psig). • If it is necessary to wash the coolers with a cleaning agent, consult Atlas Copco. Belt tensioning and replacement... - Page 84 Instruction book Model New belts Belts in use Frequency Frequency GA 5 VSD MED 17.9 11.7 GA 7 VSD MED 17.9 11.7 GA 11 VSD MED 20.8 13.9 GA 15 VSD MED 24.6 16.4 Adjusting the belt tension Step Action Stop the compressor, close the air outlet valve and switch off the voltage.
-
Page 85: Safety Valves
Instruction book Safety valves Location of safety valve Safety valve on oil separator vessel Safety valve on oil separator vessel Testing Before removing the valve, depressurise the compressor. See section Problem solving. Valve (SV) can be tested on a separate air line. If the valve does not open at the set pressure stamped on the valve, it needs to be replaced. - Page 86 Instruction book Warning No adjustments are allowed. Never run the compressor without safety valve. 2920 7104 10...
-
Page 87: Problem Solving
Instruction book Problem solving Warning • If the compressor is stopped because the supply voltage is interrupted, please be aware that it will restart automatically when the power is restored! See also section Safety precautions - general. • Before carrying out any maintenance, repair work or adjustment, stop the compressor (see section Stopping). - Page 88 If installed, check capacity of compressor room fan Oil cooler clogged Clean cooler Bypass valve malfunctioning Have valve tested Air cooler clogged Clean cooler Compressor element out of order Consult Atlas Copco Customer Centre 2920 7104 10...
- Page 89 Instruction book Condition Fault Remedy LAN symbol blinking (forced local The compressor cannot Check the ES-MED supply, CAN mode) communicate with the ES-MED and ES settings. Check the CAN network cables and connectors and local CAN settings Motor tripped The motor draws too much current Verify the ampere meter and compare to the required maximum value (see service diagram and section...
-
Page 90: Technical Data
Instruction book Technical data Readings on display Elektronikon® Graphic controller Important The readings mentioned below are valid under the reference conditions (see section Reference conditions and limitations). Reference Reading Air outlet pressure Modulates between programmed unloading and loading pressures. Compressor element Approx. - Page 91 Type Supply Frequenc Approv Current (A) (1) Q2 (A) Protection voltage (V) y (Hz) (A) (2) GA 5 VSD MED 20.9 GA 5 VSD MED 20.9 GA 7 VSD MED 24.3 GA 7 VSD MED 24.3 GA 11 VSD MED 36.3...
- Page 92 Instruction book Installation method B2 according table B.52.1. Multi-core cable in conduit on a wooden wall Maximum allowed current in function of the ambient temperature for installation method B2 Ambient temperature Cable section 30 °C 40 °C 45 °C 50 °C 55 °C 1.5 mm²...
-
Page 93: Reference Conditions And Limitations
Instruction book Ambient temperature Cable section 30 °C 40 °C 45 °C 50 °C 55 °C 25 mm² < 110 A < 96 A < 87 A < 78 A < 67 A 35 mm² < 137 A < 119 A <... -
Page 94: Compressor Data
Instruction book Air inlet temperature ˚F Relative humidity Working pressure See section Compressor data Limits Maximum working pressure See section Compressor data Minimum working pressure bar(e) Minimum working pressure psig Maximum air inlet temperature ˚C Maximum air inlet temperature ˚F Minimum ambient temperature ˚C Minimum ambient temperature... - Page 95 Instruction book Nominal motor power Oil capacity Oil capacity US gal 0.95 0.95 0.95 0.95 Oil capacity Imp. gal 0.79 0.79 0.79 0.79 Oil capacity cu. ft. 0.13 0.13 0.13 0.13 Sound pressure level (according to ISO dB(A) 2151 (2004)) Specific data for GA 7 VSD Unit GA 7 VSD...
-
Page 96: Technical Data Elektronikon® Controller
Instruction book Oil capacity cu. ft. 0.18 0.18 0.18 0.18 Sound pressure level (according to ISO dB(A) 2151 (2004)) Specific data for GA 15 VSD Unit GA 15 VSD GA 15 VSD GA 15 VSD GA 15 VSD Normal effective working pressure bar(e) 12.5 Normal effective working pressure... -
Page 97: Analog Inputs
Instruction book Digital outputs Parameter Value Number of outputs 9 (Elektronikon® Graphic controller - p.n. 1900 5200 10 …. 1900 5200 19) Type Relay (voltage free contacts) Rated voltage AC 250 V AC / 10 A max. Rated voltage DC 30 V DC / 10 A max. -
Page 98: Instructions For Use
Instruction book Instructions for use Oil separator vessel This vessel can contain pressurised air. This can be potentially dangerous if the equipment is misused. This vessel must only be used as a compressed air/oil separator tank and must be operated within the limits specified on the data plate. No alterations must be made to this vessel by welding, drilling or other mechanical methods without the written permission of the manufacturer. -
Page 99: Guidelines For Inspection
Instruction book Guidelines for inspection Guidelines On the Declaration of Conformity / Declaration by the Manufacturer, the harmonised and/or other standards that have been used for the design are shown and/or referred to. The Declaration of Conformity / Declaration by the Manufacturer is part of the documentation that is supplied with this compressor. -
Page 100: Pressure Equipment Directives
II and higher according to the Pressure Equipment Directive 97/23/EC and all pressure equipment according to the Simple Pressure Vessel Directive 87/404/EEC. Compressor type Part number Description PED Class GA 5 VSD MED up to GA 2202 8891 01 Safety valve 15 VSD MED 2202 8891 03 Safety valve... -
Page 101: Declaration Of Conformity
Instruction book Declaration of conformity Typical example of a Declaration of Conformity document (1): Contact address: Atlas Copco Airpower n.v. P.O. Box 100 B-2610 Wilrijk (Antwerp) Belgium 2920 7104 10... - Page 104 Atlas Copco's pursuit of innovation never ceases, driven by our need for reliability and efficiency. Always working with you, we are committed to providing you the customized quality air solution that is the driving force behind your business.
