NEMESIS 52
0.52-0.56 cu. in. displacement 4-stroke
Requires : 4-channel radio w/ 5 standard servos
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this
kind of engine powered precision model. Operating this model without prior preparation may
cause injuries. Remember, safety is the most important thing. Always keep this instruction
manual at hand for quick reference.
The World Models
Manufacturing Co., Ltd.
www.theworldmodels.com
A282PO25351012
Specifications
*Specifications are subject to change without notice.*
56 in / 1420 mm
524 sq in / 33.8 sq dm
5.2 Ibs / 2360 g
49 in / 1240 mm
ALMOST-READY-TO-FLY (ARF) SERIES
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
MADE IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nemesis 52 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for THE WORLD MODELS Nemesis 52

Summary of Contents for THE WORLD MODELS Nemesis 52

  • Page 1 INSTRUCTION MANUAL NEMESIS 52 0.52-0.56 cu. in. displacement 4-stroke Requires : 4-channel radio w/ 5 standard servos Specifications Wing Span 56 in / 1420 mm Wing Area 524 sq in / 33.8 sq dm Flying Weight 5.2 Ibs / 2360 g...

  • Page 2: Before You Begin

    NEMESIS 52 I N D E X BEFORE YOU BEGIN P. 1 P. 2 PARTS LIST ASSEMBLY P.3-P.12 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do.

  • Page 3: Parts List

    Parts List 1. MAIN WING -- 1 pair 10. ENGINE MOUNT PL5111050 -- 1 set SOCKET HEAD SCREW M4x25mm -- 4 pcs 2. SCREW PB2x20mm -- 4 pcs WASHER d4xD9mm -- 4 pcs CLEVIS PL4112103 -- 2 pcs STRAPER PL4112102 -- 2 pcs 11.

  • Page 4: Aileron Servo

    Main Wing Apply instant type CA glue to both sides of each hinge. Aileron Servo Lead Bottom View Aileron Servo Ø1mm pilot holes for World Models tri-horn are pre-drilled. Please look for pin-hole marks at under side of control surfaces. PB2x20mm Screw PWA2x8mm Screw PWA2x8mm...

  • Page 5: Stabilizer & Elevator

    Main Wing Please dry fit wing joiner into left and right wing to make sure they fit with the proper dihedral angle, mark the wing joiner if necessary. Apply epoxy glue to both sides of all surfaces in contact. Use a stick to apply the glue to inner side of wing joiner sleeve, and apply the glue to wing joiner before putting them together.

  • Page 6: Tail Landing Gear

    Tail Landing Gear PA3x12mm Screw PA3x12mm 1.5mm 2.1mm Collar set screw PA3x12mm Bottom View 3mm set screw Vertical Fin & Rudder Apply instant type CA glue to both sides of each hinge. C’ C=C’ Completed Elevator Pushrod Ø1mm pilot holes for World Models tri-horn are pre-drilled. PB2x12mm Screw Please look for pin-hole marks at under side of control surfaces.

  • Page 7: Rudder Pushrod

    Rudder Pushrod Ø1mm pilot holes for World Models tri-horn are pre-drilled. PB2x12mm Screw Please look for pin-hole marks at under side of control surfaces. Horn TWM PL8210010 CLEVIS WRENCH Clevis Pushrod Ø1.8x620mm Fuel Tube PB2x12mm Ø6x5mm Bottom View Main Landing Gear PM4x40mm Screw Wheel Ø...

  • Page 8: Engine Mount

    Engine Mount M4x25mm Socket Head Screw M4x25mm Socket Head Screw d4xD9mm Washer d4xD9mm Washer Engine Mount PL5111050 Blind nuts are off-centered to keep the spinner at the fuselage axis. Fuel Tank Fuel Tank 320cc Cable Tie Fuel Tank 1.5x4x400mm 320cc Double_side Tape 40x100mm A282PO25351012...
  • Page 9 Engine M3.5x30mm M3.5 Nut Socket Head Screw M3.5 Nut d3.5xD8mm Washer d3.5xD8mm Washer M3.5x30mm Throttle Pushrod Ø1.2x460mm Plastic Tube d2xD3x300mm Installed Engine Position 115 mm 4.53 in. A282PO25351012...

  • Page 10: Radio Equipment

    Servo Set 3x3mm Set Screw Linkage Connector Throttle Pushwire In c lu d e d w it h t h e r a d io S e t . M2 Nut 2mm Washer 1.5mm Throttle Servo M2 Nut Please refer to the attached sheet for linkage connector installation. Radio Equipment Install and arrange the servos as shown in the diagram.
  • Page 11 Main Wing HM4x25mm Screw d4xD12mm Washer Plywood HM4x25mm 2x30x114mm Socket Head Screw ( Wing Protection ) d4xD12mm Washer Completed Cockpit First insert the grommet to the canopy then apply screw. PWA2.3x8mm Screw d1.5xD6.5mm SIlicon Grommet Completed PWA2.3x8mm d1.5xD6.5mm SIlicon Grommet P.10 A282PO25351012...
  • Page 12 Cowling & Spinner Please refer to the attached sheet for usage of the transparent 3D template. PWA2.6x12mm Screw First insert the grommet to the cowling then apply screw. d1.5xD6.5mm SIlicon Grommet Spinner Ø70mm Cowling d1.5xD6.5mm SIlicon Grommet PWA2.6x12mm Completed Fuselage Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams.

  • Page 13: Control Throws

    # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. is specially designed to be powered by 4C 0.52-0.56 engine, using a more NEMESIS 52 powerful engine does not mean better performance. In fact, over powered engine may cause structural damage and injuries.
  • Page 14 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
  • Page 15 Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
  • Page 16 A282PO25351012...
