Parts List

1. MAIN WING (Lower) -- 1 pc.
2. SCREW PM2x12mm -- 4 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
STRAPER -- 2 pcs
CLEVIS -- 2 pcs
HORN -- 2 sets
PUSHROD Ø1.4x75mm w/ Threads (For Aileron) -- 2 pcs
PLYWOOD 3x6x15mm (For Aileron Servos) -- 4 pcs
3. MAIN WING (Upper) -- 1 pc.
4. STABILIZER & ELEVATOR -- 1 set
FUSELAGE -- 1 pc.
SCREW PM2x8mm -- 2 pcs
ELEVATOR LINK PL4510010 -- 1 pc.
BASLA 4x12x34.7mm -- 1 pc.
5. VERTICAL FIN & RUDDER -- 1 set
6. TAIL LANDING GEAR -- 1 set
TAIL WHEEL Ø23mm -- 1 pc.
PLASTIC COLLAR d1xD5x2mm -- 2 pcs
SCREW PA2x8mm -- 2 pcs
SCREW PM2x8mm -- 1 pc.
M2 NUT -- 1 pc.
ALUMINUM PLATE 0.3x8x22mm -- 1 pc.
7. SCREW PM2x10mm -- 2 pcs
CLEVIS -- 1 pc.
FUEL TUBE d2xD4x4mm -- 1 pc.
HORN -- 1 set
PUSHROD Ø1.4x520mm w/ Threads (For Rudder) -- 1 pc.
8. FUEL TUBE d2xD4x4mm -- 1 pc.
CLEVIS -- 1 pc.
PUSHROD Ø1.4x490mm w/ Threads (For Elevator) -- 1 pc.
9. KM0283010 OUTRUNNER MOTOR -- 1 set
HW2340100 PROPELLER ADAPTOR (d3 D5) -- 1 set
FOLDING PROPELLER SET PL6314020 -- 1 set
SCREW PWA2x8mm -- 4 pcs
SCREW PM3x6mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
COWLING -- 1 pc.
SPINNER Ø45mm -- 1 set
10. MAIN LANDING GEAR -- 1 pc.
MAIN WHEEL Ø40mm -- 2 pcs
WHEEL PANTS -- 1 pair
SCREW PM2x6mm -- 7 pcs
SCREW PM3x25mm -- 2 pcs
M3 NUT -- 2 pcs
WASHER d3xD7mm -- 2 pcs
WASHER d2xD5mm -- 4 pcs
M2 NUT -- 4 pcs
10. MAIN LANDING GEAR -- 1 pc.
MAIN WHEEL Ø40mm -- 2 pcs
WHEEL PANTS -- 1 pair
SCREW PM2x6mm -- 3 pcs
SCREW PM3x25mm -- 2 pcs
WASHER d2xD5mm -- 7 pcs
WASHER d3xD7mm -- 4 pcs
M3 NUT -- 2 pcs
SCREW PA2x6mm -- 4 pcs
COLLAR Ø3.1mm w/ Set Screw -- 2 sets
COPPER TUBE d3.1xD4x5mm -- 2 pcs
ALUMINUM PLATE 0.5mm -- 2 pcs
11. STRAPER -- 2 pcs
FUEL TUBE d2xD4x4mm -- 2 pcs
SCREW PM2x10mm -- 1 pc.
WASHER d2xD5mm -- 1 pc.
M2 NYLON INSERT LOCK NUT -- 1 pc.
BATTERY TIE -- 1 pc.
SPONGE 10x80x150mm (For Radio Equipment) -- 1 pc.
DOUBLE-SIDED TAPE 30x35mm -- 1 pc.
MOUNTING PLATE 5x15mm PL4114015 -- 1 pc.
PLYWOOD 2x56x96mm -- 1 pc.
12. CANOPY -- 1 pc.
SCREW PWA2x8mm -- 4 pcs
PILOT (050) -- 1 pc.
13. NYLON BOLT M2.5x20mm -- 2 pcs
NYLON WASHER d2.6xD9mm -- 2 pcs
PLASTIC PLATE 1x25.5x63.7mm (Wing Protection) -- 1 pc.
14. SCREW PWA2.3x12mm -- 4 pcs
SCREW PM2x14mm -- 2 pcs
SCREW PM2x8mm -- 4 pcs
WASHER d2xD5mm -- 12 pcs
M2 NYLON INSERT LOCK NUT -- 6 pcs
PLYWOOD 3x53x170mm (Side Cabane) -- 2 pcs
FOAM 3x204x209mm (Wing Incidence Angle Template) -- 2 pcs
ALUMINIUM PLATE (Brace: Fueslage to Wing) -- 1 set
15. SCREW PM2x8mm -- 8 pcs
HORN -- 4 sets
CLEVIS -- 4 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
PUSHROD Ø1.4x138mm w/ Threads (For Aileron to Aileron) -- 2 pcs
16. DECALS -- 1 set
COVERING:--
PURPLE COLOR SCHEME:
LIGHTEX SGX100 WHITE
LIGHTEX SGX201 BLACK
LIGHTEX SGX312 BRIGHT RED
LIGHTEX SGX370 SILVER
LIGHTEX SGX561 PEARL PURPLE
YELLOW COLOR SCHEME:
LIGHTEX SGX100 WHITE
LIGHTEX SGX201 BLACK
LIGHTEX SGX312 BRIGHT RED
LIGHTEX SGX370 SILVER
LIGHTEX SGX330 CADMIUM YELLOW
