5. Screw in Red Knobs
a. Locate the holes near the center of each
rail. On both sides, screw the red knob
through the hole in the laser arm to
secure the laser arm to the rail. They
must be screwed in as tight as your
fingers will permit, but do not use a tool to
tighten them.
6. Insert the Rear Foam Lid and Front Foam Block
a. Place the lid of the rear foam block,
covering the printer head and power
cord. Place the final foam block in the
front of your unit and close the front door.
7. Close the Lid and Box Glowforge
a. Make sure the two black foam shells are
in the bottom of the box. ​ H ave two people
lift the Glowforge unit into the box. ​ T he
unit will fit snugly into the foam inserts.
