Glowforge Manual page 20

Note: Your Pro Shields will be shipped later this year. ​ T hey'll finger-screw right into the
passthrough slot of your Glowforge Pro to
ensure that nothing - material or laser light -
comes in or out when the slot is not in use.
For more information about the Pro Glasses
and Pro Shields, see the Glowforge Pro
Training Materials.
Slide In the Crumb Tray
The black and metal crumb tray sits inside the bed of your Glowforge, supports the material you
place inside, and catches leftover print bits to keep your Glowforge nice and tidy. It has four little
feet that rest in four little dimples. The handle goes in front, and the feet go on the bottom.
1. Lift the lid of your Glowforge & lower the front door
2. Gently move the Laser Arm
a. Using two hands, gently push the laser arm away from you until it's near
the back of the unit.
3. Pick up the Crumb Tray
a. Pick up the crumb tray - make sure the handle is in front and the wide black
plastic strip is in the back.
4. Slide in the Crumb Tray
a. Slide it in until you feel the feet settle into
the dimples in the base of the Glowforge
unit.
5. Make Sure the Handle is in Front
a. Check that the handle's in the front, and the wide black part is in the back, just
like the picture. Otherwise, you'll have mysterious printing problems, and feel silly
when we ask you if your tray is in backwards.
