6. Close the Front Door.
Snap in the Printer Head
Never connect or disconnect the printer head while the Glowforge is plugged in or you might
break something.
1. Position the Laser Arm and Metal Plate
a. Gently slide the metal plate on the laser
arm all the way to the right, then push the
arm to the back of the unit.
2. Carefully Pick Up the Printer Head
a. Do not touch any part of the printer head that is
not flat black metal. Be especially careful of the
yellow window on the side of the head. R​ e move
the printer head from the white foam tray and
remove the orange foam cylinder from inside the
head.
3. Pick Up the Wire Ribbon
a. Holding only the finished black surfaces of
the printer head, pick up the printer head
and wire ribbon as shown.
