Glowforge Manual page 23

Set Up Exhaust
1. Connect Hose to Unit
a. Use the hose provided. Slide the hose clamp around the hose and then fit both
items together over the exhaust connection on the back of your Glowforge
printer. Using a flathead screwdriver, tighten the clamp until it will not come off
with a gentle tug. Careful: Over-tightening can damage the tube and risk exhaust
leakage.
2. Connect Hose to Vent
a. Connect the other end of the hose to your outdoor exhaust vent. Keep the hose
as straight as you can, with no more than two turns of 90 degrees or less. Make
sure the hose isn't twisted, pinched, kinked, or flattened.
3. Disconnect Hose After Use
a. Changing weather conditions may cause hot, cold, or humid air to enter your
Glowforge that could damage it. When your Glowforge is not in use, remove the
hose from the vent or window, or disconnect it from your Glowforge.
Connect to electrical power
1. Make sure your Glowforge is turned off
(O is depressed) and then connect the
power cable.
2. Plug the Glowforge into a grounded wall
outlet with 800 watts of power available.
3. Turn on your Glowforge by pressing the
switch so the "l" side is depressed.
4. Lights will come on, the head will move,
and you might hear a bubbling sound.
Copyright Glowforge, Inc. 2017
DRAFT
