Glowforge Manual page 35

Pack the Unit Safely
It's important to package your Glowforge properly with the original boxes, foam blocks, and
important orange and red bits.
1. Place Red Strip on Both Rails
a. Push the laser arm to the back of the
unit. Set the red silicone strips on the
rails near the center of the unit with the
knobby bit close to you as pictured.
2. Position Laser Arm
a. Slide the laser arm forward so that it's
resting on the silicone strips. You'll need to pick it up just a bit at the front, then
the back, like taking a baby carriage up a curb.
3. Attach the Clip
a. The clip snaps onto the bottom of the laser
arm and pokes up into the metal plate. Align
the left tab of the clip with the hole on the
right side of the plate, then hook the back of
the laser arm and pull the clip towards you
and up. (It's much easier than it sounds.)
When the clip is in place, the metal plate
will no longer slide from side to side.
4. Insert the Rear Foam Block
a. With the lid removed, insert the foam
block containing the printer head and
power cord into your Glowforge. The
bottom will lay flat against the floor of
your unit.
