8 Specifications
Power
2 AA, common alkaline batteries.
Display
Dot graphic LCD display
Operational Keys
Power, Wire, Escape/Clear (ESC), Next (
function and label, depending on the specific menu in use
Operational Annunciators
Unit of measure, battery level
Display Resolution
2,000 lbf/ 10 kN/ 1000 kgf Quick-Check instrument:
10,000 lbf/ 45 kN/ 4500 kgf Quick-Check instrument:
lbf (pound-force)
kgf (kilogram-force)
N (Newton)
Custom units
For ease of use, the display always counts by a multiple of 1, 2 or 5.
Quick-Check Red User Instructions
lbf (pound-force)
kgf (kilogram-force)
N (Newton)
Custom units between 101 & 200
between 101 & 200
) and four softkeys with changing
Displayed resolution setting
Low Med
10 lbf 5 lbf
5 kgf 2 kgf
50 N 20 N
between 201 & 500
divisions divisions
Displayed resolution setting
Low Med
50 lbf 20 lbf
20 kgf 10 kgf
200 N 100 N
between 201 & 500
divisions divisions
High
2 lbf
1 kgf
10 N
between 501 & 1000
divisions
High
10 lbf
5 kgf
50 N
between 501 & 1000
divisions
