Check-line CDT-1000HD Operating Instructions Manual

Non-contact tachometer
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
9.0 SPECIFICATIONS
Measuring Ranges
RPM
1.00 - 99,999 rpm (non-contact)
Resolution
.01 from 0 -100
.1 from 100 - 1,000
1 from 1000 - 99,999
Accuracy
± 0.02% of reading or ±1 digit
Display
5-Digit LCD, 10mm high
Decimal Point
Automatic
Memory System
Maximum, minimum, last reading and average (retained
in memory for the life of batteries)
Measurement System
Non-Contact
Visible LED light beam
Engineering units
RPM
RPM
Sensing Distance
Up to 24 inches (60 cm)
Display Update Time
0.5 seconds
Auto Power Off
After 30 seconds of non-use (minimum, maximum,
last and average reading retained in memory)
Battery Life
30 hours continuous use, approx.
Battery Type
2 AA (1.5V) or rechargeable
Weight
5 ounces (140 grams)
Housing Material
ABS Plastic
Operating Temperature
32 to 122° F (0 to 50° C)
Storage Temperature
- 4 to 150° F (-20 to 70° C)
Accessories Included
Reflective tape, 2 AA batteries and operating instructions
in a foam-fitted, hard-plastic carrying case,
NIST-traceable calibration certificate
Warranty
5 years
10.0 SPARE PARTS
P/N: CDT-TAPE
10 strips of reflective tape-1/2" x 4" (12 x 100mm)
8
OI407G-1000

TABLE OF CONTENTS

01.0
02.0
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
03.0
CONTENTS OF COMPLETE OUTFIT . . . . . . . . . . . . . . . . . .3
04.0
OVERVIEW OF CDT-1000HD . . . . . . . . . . . . . . . . . . . . . . . . .4
05.0
INSTALLING BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
06.0
REMOVING PROTECTIVE RUBBER SHELL . . . . . . . . . . . .5
07.0
MEASURING RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
08.0
MEMORY SYSTEM
99.0
SPECIFICATIONS
10.0
SPARE PARTS
11.0
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDT-1000HD and is the answer not in the manual?

Questions and answers

Related Manuals for Check-line CDT-1000HD

Summary of Contents for Check-line CDT-1000HD

  • Page 1: Table Of Contents

    ± 0.02% of reading or ±1 digit 04.0 OVERVIEW OF CDT-1000HD ......4 Display 5-Digit LCD, 10mm high 4.1 LCD Display...

  • Page 2: Introduction

    The CDT-1000HD is supplied with a built-in memory system which permits A measuring period is the interval of time while the Measure key is the user to recall the maximum, minimum and last reading to the display for depressed.

  • Page 3: Contents Of Complete Outfit

    2. If the rotating element is highly reflective, cover it with black tape or paint to improve the contrast between the reflective tape and the surface of the rotating element. The CDT-1000HD is supplied with the following accessories in a foam-fitted, carrying case: 1. Meter with molded rubber shell 2.

  • Page 4: Overview Of Cdt-1000Hd

    4.0 OVERVIEW OF CDT-1000HD 5.0 INSTALLING BATTERIES 1. Turn the gauge over and locate the battery compartment. You do not have to remove the rubber shell. 2. Open the battery compartment by pulling down on the tab located at the top of the battery cover and remove the cover.

  • Page 5: Warranty

    12.0 WARRANTY ELECTROMATIC Equipment Co., Inc. (ELECTROMATIC) warrants to the original purchaser that this product is of merchantable quality and confirms in kind and quality with the descriptions and specifications thereof. Product failure or malfunction arising out of any defect in workmanship or material in the product existing at the time of delivery thereof which manifests itself within one year from the sale of such product, shall be remedied by repair or replacement of such product, at ELECTROMATIC’s option, except where unauthorized repair, disassembly, tamper-...
  • Page 6 ® CHECK LINE • BY ELECTROMATIC CDT-1000HD Non-Contact Tachometer Distributed by: ABQ Industrial LP USA Tel: +1 (281) 516-9292 / (888) 275-5772 eFax: +1 (866) 234-0451 Operating Instructions Web: https://www.abqindustrial.net E-mail: info@abqindustrial.net...
