NOTES
16
OI407G-2000

Table of Contents

01.0
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02
02.0
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 03
03.0
Contents of Complete Outfit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
04.0
Overview of CDT-2000HD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
05.0
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
06.0
Measuring RPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 07
07.0
Measuring Surface Speed or Length . . . . . . . . . . . . . . . . . . . . . . . . . . 09
08.0
Using Optional Surface Speed Wheels . . . . . . . . . . . . . . . . . . . . . . . . . 10
09.0
Memory System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10.0
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11.0
Spare Parts & Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
12.0
Removing the Protective Rubber Shell . . . . . . . . . . . . . . . . . . . . . . . . . 14
13.0
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDT-2000HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Check-line CDT-2000HD

Summary of Contents for Check-line CDT-2000HD

  • Page 1: Table Of Contents

    04.0 Overview of CDT-2000HD ........05 4.1 LCD Display 4.2 Front Panel Key Functions...

  • Page 2: Introduction

    WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT The CDT-2000HD can also be used to measure the accumulated total of LIMITED TO, THE WARRANTY OF MERCHANTABILITY AND continuously running material such as paper, wire/yarn being wound on a FITNESS FOR ANY PARTICULAR PURPOSE OR APPLICATION.

  • Page 3: Safety Precautions

    2.0 Safety Precautions 12.0 Removing Protective Rubber Shell The gauge is supplied with a durable rubber shell that provides an added All operators should wear safety goggles when using this or any other measure of physical and environmental protection in harsh applications. tachometer.

  • Page 4: Contents Of Complete Outfit

    11.0 SPARE PARTS & OPTIONAL ACCESSORIES 3.0 CONTENTS OF COMPLETE OUTFIT The CDT-2000 is supplied with the following accessories in a foam-fitted, carrying case: Standard Spare Parts 1. Meter with molded rubber shell 2. Slide-on Contact Adapter CDT-ADAP Slide-In Contact Adapter 3.

  • Page 5: Overview Of Cdt-2000Hd

    10.0 SPECIFICATIONS 4.0 OVERVIEW OF CDT-2000HD Measuring Ranges – rpm Optical 1 – 99,999 rpm Mechanical 1 – 99,999 rpm Measuring Ranges – speed Wheel Size 6" 12" 0.1 m m/min 0.10–1524 0.40–609.6 0.10–1999 ft/min 0.40–5000 0.40–2000 0.40–6550 in/min 4.0–60.00 4.00–24.000...

  • Page 6: Installing Batteries

    2. Press the MEM key to recall the desired value battery cover and remove the cover. The Memory key accesses the CDT-2000HD’s built-in Insert two AA batteries following the memory. Each time the MEM key is pressed the values...

  • Page 7: Measuring Rpm

    8.0 USING OPTIONAL-SIZED SURFACE SPEED WHEELS 6.0 MEASURING RPM 6.1 Contact Operation - RPM The following wheels can be used with the CDT-2000HD 1. Install the Slide-on Contact Adapter. Push on securely 1.2" 3.8" 1.9" (32mm) (97mm) (49mm) 2. Slide the Cone Tip adapter over the shaft of the instrument.

  • Page 8: Non-Contact Operation

    6.2 Non-Contact Operation - RPM 7.0 MEASURING SURFACE SPEED OR LENGTH Install the Slide-on Contact Adapter. 1. Remove the Contact Adapter. 2. Attach a small piece of the supplied reflective tape to the rotating element (shaft, pulley, etc.). 2. Slide the Surface Speed Wheel over the shaft of the instrument.
  • Page 9 CHECK LINE ® • BY ELECTROMATIC CDT-2000HD Digital Tachometer ELECTROMATIC CHECK LINE ® • O ., 600 Oakland Ave., Cedarhurst, NY 11516–U.S.A. INSTRUMENTS • Operating Instructions TEL: 516-295-4300 FAX: 516-295-4399...
