2.3 Important Features
Quick to use
Direct tension readings
Portable & rugged
Accurate
Multiple wire size storage
2.4 Using Quick Check (Red) with EDXtreme PSU
The Quick Check can be connected to the EDX PSU via the Comm Port. This 120VAC/
240VAC external power supply will supply power to the Quick Check instead of AA
batteries.
2.4.1 Quick Check Connector
The connector on the Quick Check is recessed for protection. Lift the protective cap to
access the connector. It is used to connect the instrument to a printer, PC or external
power supply. See your Dillon distributor for details.
12
Attaches and removes from tensioned line in
seconds.
Quick-tensioning readout for ultra fast line
tensioning.
No more complicated lookup charts! Save time
and improve accuracy.
Designed for outdoor use.
Employs Weigh Bar
weighing.
Stores up to 20 different calibrations.
Figure 2.3 Quick Check Connector
®
technology used for precise
Quick-Check Red User Instructions
