Check-line CTM2 Instruction Manual page 23

Setup
Press the Setup softkey and you will see these choices; Power, PtFmt, Misc, About,
Test and Clock. These are described below:
Setup
Power PtFmt Misc.
Choose default
print format: 1 - 5
Peak Capture Rate:
(100Hz – Normal),
(1KHz – High Speed),
(10Hz – Battery Saver)
Date/Time
(Enabled,
Disabled)
Enable Auto-
Shutdown:
(Yes or No)
Flash
Enable Key
Blink:
(Yes or No)
Power:
Use this to set power management features
Be aware that 1kHz - High Speed mode will consume more battery power.
Quick-Check Red User Instructions
About Test Clock
Batt A-D
View Battery View Counts and
Voltage Cal. factor
Device Calib. 0.Load
Display Device
View Over load
info, SN, FW and
counter and log
PN
Points Re-Cal
View all
To view when
Calibration
calibration is due
points
Zero Contr BLite
Choose Zero Key
Adjust Contrast
clears Peak: Inten
Up or DOWN
(Yes or No)
Choose backlight
Set AZT (div): .5
intensity: 1- 10
Set Motion
Range (div): 1
Set Filter
(*40)
Figure 3.7 Setup Menu
Peak Capture Rate - Select a Peak Capture Rate by using the Sel keys to
l
scroll through the choices. Choices are 100Hz - Normal, 1kHz - High
Speed, and 10Hz - Battery Saver (default). Press Enter to accept the
displayed setting.
Disp Keys Comm
Press KEY to
Run display test test. Press ESC
key to exit
Zero Ntwrk Cell
View Dead load View Radio
Analysis information
Print
Print Calibration
report
Mode
Selected
Backlight ON,
OFF or Timer
operation
If Timer enabled
then: Enter time
in Seconds
Choose Motion
Reset Timer:
(Yes or No)
Setpts
Setpt1 Setpt2
COM1 RADIO
23
