GLOBAL MENU
Alternatively, instantly activate or deactivate voice to main or voice to FX using the [TRIG] keys 1-4 and 9-12,
respectively. Red LEDs above these sets of keys will show if the voice is active (full-bright) or inactive (half-
bright).
Note that voice routing can be set and stored for each individual kit, and that these settings override the
GLOBAL voice routing unless they are set not to (see KIT MENU, page 19).

SYSEX DUMP

In the SYSEX DUMP menu, kits, Sounds, patterns, songs and global slots can be sent and received. Select a
menu option using [UP]/[DOWN] or the SOUND SELECTION wheel. Press [YES/SAVE] to open the high-
lighted menu selection.
When receiving or sending SysEx data, the MIDI ports or the USB port of Analog Keys must be connected to the
external sending/receiving device.
•
If Analog Keys is sending or receiving SysEx data through the MIDI ports, use the Elektron TM-1
USB MIDI interface for up to 10x transfer speeds.
•
If the external device is a computer, we recommend using our free SysEx utility C6, which can be
downloaded from the Elektron website.
SYSEX SEND
Here kits, Sounds, patterns, songs and global slots can be sent to an external device via the MIDI OUT port or
the USB port of Analog Keys.
The column to the left selects what will be backed up. Select the column using the [LEFT] arrow key. Use the
[UP]/[DOWN] keys or the SOUND SELECTION wheel to scroll through the column. The SysEx data send alter-
natives located in the column to the right will change depending on the selection made in the left column. Press
the [RIGHT] arrrow key to access this column. Use the [UP]/[DOWN] keys or the SOUND SELECTION wheel
to select what will be sent. Press [YES/SAVE] to initiate the SysEx send procedure.
ALL offers the possibility to do complete backups of various data.
60
• WHOLE PROJECT will send all kits, Sounds, patterns, songs and global slots to the
receiving device. I.e. the complete project.
