GLOBAL MENU
•
In MULTI MAP EDIT, Setting a specific SOUND SLOT and setting SOUND INC to 1 is convenient if
you wish to define, for example, a succession of drum sounds that you have stored in a given
sound slot range to be mapped to a certain section of the keyboard. Instant access to those
snares, kicks and hihats!
•
If you intend to use your custom multi map with an external MIDI keyboard, remember to set the
external MIDI keyboard to the assigned PERF CHANNEL (or change the performance channel in
the MIDI CHANNEL menu to that of the MIDI keyboard)

CV CONFIG

CV/Gate output signals are calibrated and set up in this menu.
CV A-D CONFIG
Each of the subpages are identical and one for each CV/Gate output exists. The list of available parameters in
this menu will depend on the menu settings. When the CV Track is active, pressing [FUNCTION] + [CV A-D] is
an alternate way of opening this menu for each corresponding CV/Gate output.
Please read the following paragraphs on how to set up CV pitch control. CV pitch is configured by finding the
voltages generating two different notes from the synthesizer you wish to control. To get a good result you should
select the notes two or three octaves apart.
FIXED VEL will, if set to OFF, make the velocity sensitivity of the MIDI keyboard
work as usual. It may also be set to a constant specific value between 1 and
127.
DELETE ENTRY deletes the whole entry. Select and reconfirm by pressing
[YES/SAVE].
INSERT BEFORE will create a new entry with a range ending on the note
preceding the current entry. Select by pressing [YES/SAVE].
INSERT AFTER will create a new entry with a range beginning on the note suc-
ceeding the current entry. Select by pressing [YES/SAVE].
