Exit
After setting up the holiday period, you are now ready to enter the 24-hour program
that the controller should follow during this period:
To exit the holiday plan facility:
1. Press until the
2. Press .
EY.65.H4.02
11. In the Holiday picture, press
The ECL 2000 displays this picture, which allows you
to select an operating mode for the holiday. The X indi-
cates the currently selected mode (Stand-by in the ex-
ample).
12. Use and to move the cursor between Stand-
by and Automatic.
13. Use and to select or deselect an operating
mode (see page 3 for information about ECL
2000's operating modes).
When you select Automatic, a time line appears at the
bottom of the display.
14. Press to move the cursor to the time line.
The time of day corresponding to the cursor position is
displayed.
Now you can set the 24-hour program for the holiday
period in the same way as you set a 24-hour program for
the normal 7-day plan:
selects comfort temperature (thick time line) and
selects night setback temperature (thin line). See page
17 for more detailed instructions.
symbol appears at the top right corner.
Time Programming
.
and move the cursor,
19
