Installation Guide
ESMR
ENGLISH
ESMR
1. Feed cable through the inlet in center
of the backplate or through the left
side inlet. Press the orange tabs to
connect wires. Polarity not important.
2. Mount on wall with screws (not
included).
3. Snap on cover over hooks at top and
bottom.
Removal of cover
4. Press tabs to remove cover.
© Danfoss | 2021.09
DANSK
ESMR
1. Før kablet gennem åbningen i
bagpladens centrum eller gennem
åbningen i venstre side. Tryk på
de orange paler for tilslutning af
ledninger. Polaritet er ikke vigtig.
2. Montér på væg ved hjælp af skruer
(ikke medleveret).
3. Klik frontdækslet på bagpladen i
henholdsvis top og bund.
Aftagning af frontdæksel
4. Tryk på tappene for at aftage
frontdækslet.
AN39112973488901-000101 | 1
Advertisement
Related Manuals for Danfoss ESMR
Summary of Contents for Danfoss ESMR
- Page 1 3. Snap on cover over hooks at top and bottom. 3. Klik frontdækslet på bagpladen i henholdsvis top og bund. Removal of cover Aftagning af frontdæksel 4. Press tabs to remove cover. 4. Tryk på tappene for at aftage frontdækslet. © Danfoss | 2021.09 AN39112973488901-000101 | 1...
- Page 2 “C” = Terminal block for cable connection “C” = Klemrække for ledningsforbindelser “D” = Cover “D” = Frontdæksel ? ESMR: www.danfoss.com ? https://www.youtube.com/user/DanfossHeating -> Playlists -> How-to Videos -> District Energy installation videos *087H9341* 2 | © Danfoss | DCS-SGDPT/DK | 2021.09 AN39112973488901-000101...
