- Page 1 Electronic, 2-channel CP715 Si common timebase programmer for heating & hot water Installation & User Instructions (Including 24V models)
-
Page 2: Table Of Contents
Index Installation Instructions Product specifi cation and Installation Installation and Wiring DIL switch settings Advanced Programming Options Copy Functions Service Interval Timer Wiring Conversion 8-15 User Instructions Your programmer Preset programmes Resetting the unit 24hr or AM/PM display Setting the Date, Time and Day 18-19 Accepting the preset programmes Changing the preset programmes... -
Page 3: Installation Instructions
Installation Instructions Please Note: This product should only be installed by a qualifi ed electrician or competent heating installer, and should be in accordance with the current edition of the IEEE wiring regulations. Product specifi cation Specifi cation 230V model 24V model Power supply 230 Vac,... - Page 4 For wiring connections refer to diagram below. CP715 Si models are double insulated and do not require an earth connection, however a parking terminal is provided on the wallplate. This is clearly marked with an Earth symbol.
-
Page 5: Dil Switch Settings
DIL Switch Settings Before mounting the unit, ensure the SW.1 3 ON/OFFs 2 ON/OFFs 4 DIL switches on the rear have been SW.2 GRAVITY PUMPED SW.3 5/2 DAY 7 DAY or 24 HOUR moved to the required settings. SW.4 7 DAY 24 HOUR Tick the INSTALLER SETTING box on the inside fl... - Page 6 Copy Functions Explained There are 3 possible copy functions available. These are; Standard Copy, Enhanced Copy, and AB copy. Copy functions are enabled/disabled in the Advanced Programming Options (page 5). Standard Copy: Pressing copy will copy the previous days events into the displayed day. The unit will then display the 1st event for the new day.
-
Page 7: Service Interval Timer
NEXT (next period) buttons. Service Interval Timer The CP715 Si is fi tted with an installer setback service interval timer. If this feature is required please contact our technical department. Setting instructions for this gas safety feature are... -
Page 8: Wiring Conversion
(applies only to 230 volt models) Wiring conversions can be used when replacing the following programmers with the CP715 Si. Some time controls are connected diff erently depending on the type of system they are controlling. Consult the column headed “NOTE This conversion ... - Page 9 Table B (pages 12-15) should be used. If in any doubt, contact our Technical Services Department before proceeding with the replacement. *Any wires connected to switch COMMONS which are linked LIVE on existing wallplates must be transferred to the LIVE terminal on the new wallplate An additional terminal Wires other block may be required...
- Page 10 Table A cont.. MAINS DANFOSS RANDALL FP715, CP715 (PUMPED) SANGAMO S409/3 SATCHWELL LIBRA & DHP 2201 SATCHWELL ET 1401 & 1451 SMITHS IND. CENTROLLER 90 SMITHS IND. CENTROLLER 1000 SWITCHMASTER 800 & 805 SWITCHMASTER 900 & 9000 SWITCHMASTER SONATA VENNER CHC/W2 (WITH STAT)
- Page 11 An additional terminal Wires other block may be required than links in NOTE where these discon- these terms This conversion applies nected leads (or pairs) go to LIVE only if..should be terminated Programme selectors UNLINKED Programme selectors UNLINKED Used in a system having independent control of water and heating...
- Page 12 HORSTMANN 425 DIADEM HORSTMANN 525 & 527 HONEYWELL ST669 POTTERTON EP2000, EP3000 RANDALL TSR2P RANDALL MKII R6 DANFOSS RANDALL 3060 & 3020P RANDALL 701 DANFOSS RANDALL SET 2 SANGAMO M5 410 FORM 4 SANGAMO S409 FORMS 1 & 4 N,1,3...
- Page 13 An additional terminal Wires other block may be required than links in NOTE where these disconnected these terms This conversion leads (or pairs) should be go to LIVE applies only if..terminated Programmed selectors UNLINKED OILER STAT Programme selectors UNLINKED Programme selectors UNLINKED ...set for gravity HW...
- Page 14 Table B cont... MAINS DANFOSS RANDALL FP715, CP715 (PUMPED) SMITHS IND. CENTROLLER 1000 SMITHS IND. CENTROLLER 60 SMITHS IND. CENTROLLER 10 SMITHS IND. CENTROLLER 70 SMITHS IND. CENTROLLER 1000 SWITCHMASTER 320 & 350 SWITCHMASTER 400 SWITCHMASTER 600 SWITCHMASTER 900 & 9000...
- Page 15 An additional terminal Wires other block may be required than links in NOTE where these discon- these terms This conversion nected leads (or pairs) got to LIVE applies only if..should be terminated Programme selectors UNLINKED L & 4 are LINKED Programme selectors UNLINKED Used in a system having...
- Page 16 The text below has been edited and approved by the Plain English Campaign, who has issued a Crystal Mark to be displayed with it. What is a programmer? ... an explanation for householders. Programmers allow you to set ‘On’ and ‘Off ’ time periods. Some models switch the central heating and domestic hot water on and off...
-
Page 17: Your Programmer
User Instructions Your programmer The CP715 Si allows you to switch your heating and hot water on and off at times that suit you. You can programme up to 3 ON/OFF times per day for the heating and the hot water and the two systems can be operated independently. -
Page 18: Before You Start
Before you start Open the fl ap on the front of the clock. Press the RESET button using a non-metallic object (e.g. pencil/matchstick) until you hear a click and the 2 red lights on the front of the unit fl ash once. -
Page 19: Accepting The Preset Programmes
Press DAY/HOL to display day and month. Use the + or - buttons to set the correct month (Jan = 1, Feb = 2 etc.). Press DAY/HOL to display day and month. Use the + or - buttons to set day of month. - Page 20 Before you change the preset programmes Your installer will have set your unit to operate in one of the following modes: 5/2 day - one set of programmes for weekdays and another for weekends (page 21-22) 7 day - diff erent settings for each day of the week. (page 23-24) 24 hour - one set of programmes for the whole week.
- Page 21 Programming the heating and hot water in 5/2 day mode Press PROG once until SET ON DAY/HOL TIME appears at the top of the display MOTUWETHFR appears at the bottom of the display. Use the + or - buttons to set the time you would like your heating/hot water to fi...
- Page 22 Press the DAY/HOL button DAY/HOL once and SASU will appear at the bottom of the display. To set the times required for DAY/HOL SA and SU repeat steps 1-3 or if the same settings are required press COPY. Press the PROG button to DAY/HOL return the unit to RUN mode (time appears &...
- Page 23 Programming the heating and hot water in 7 day mode Press PROG once until SET ON DAY/HOL TIME appears at the top of the display. Note the current day is displayed. Press the DAY/HOL button until the required day is displayed.
- Page 24 Press the PROG button to return DAY/HOL the unit to RUN mode (time appears & colon in the display begins to fl ash) Proceed to page 26.
- Page 25 Programming the heating and hot water in 24 hour mode Press PROG once until SET ON DAY/HOL TIME appears at the top of the display. Use the + or - buttons to set the time you want your heating/hot water to fi rst come on in the morning (Event 1).
- Page 26 Running your Programme To run the central heating programme: press the SELECT button next to the radiator symbol. To run the hot water programme: press the SELECT button next to the tap symbol. As you press the SELECT button the display will change between ON, ALLDAY OFF, ALLDAY and AUTO.
-
Page 27: Temporary Overrides
Temporary override buttons Sometimes you may need to change the way you use your heating temporarily, i.e. due to unusually cold weather. The CP715 Si has two convenient overrides which can be selected without aff ecting the set programme. +1HR... -
Page 28: Holiday Programme
Holiday Programme To automatically bring the heating back on when returning from holiday the CP715 Si has a built in holiday feature. Follow the steps below to set the date that the heating system needs to come back on. Press DAY/HOL... - Page 29 Changing clocks forward & back This is handled automatically. Should the installer have turned off Automatic Time Change then follow the instructions below. Open the fl ap on the front of the unit to reveal the programming buttons. To change from Summer to Winter (clocks back) - press and hold - button To change from Winter to Summer...
-
Page 30: Service Interval Timer
Service Interval Timer If the property is owned by a landlord he may, for gas safety reasons, have instructed the installer to set the service interval timer. If set, 28 days prior to the boiler service due date, a momentary visual and audible warning will remind you to have the boiler serviced in the next 28 days. - Page 31 Making a Full Reset If it is necessary to fully reset the unit, excluding the date and time, follow the instructions below. Press and hold the +1HR and MAN buttons on the left hand side of the product. +1HR +1HR Press the RESET button and hold for 3 seconds.
-
Page 32: Hot Water
Fault Check List o Hot Water heck FP715 programmer. Turn the heating selector to OFF and the water selector to ON. CP715 Is the red light by the water switch on? heck fuse in fused spur heck cylinder thermostat Is the stat set to a temperature of 60° ? Turn knob to 60°... - Page 36 Call our technical department 0845 121 7505 (8.45-5.15 Mon-Thurs, 8.45-4.45 Fri) For a large print version of these instructions please contact the Marketing Services Department on 0845 121 7400. Danfoss Randall Ltd Ampthill Road Bedford MK42 9ER Tel: 01234 364621 Fax: 01234 219705...
