Description This output indicates that the BusR is healthy. The output is closed while all
BusR electrical parameters are in limits. If BTB is closed, the output
deactivates after the the delay for fixed voltage or frequency protections
elapses. If BTB is opened, the output deactivates immediately after electrical
parameters get out of limit (e.g. frequency, voltage, voltage unbalance etc.).
15.2.1.47 Binary output: TimerAct 1-4
Related FW 3.0
Description This is combined output from timer channels 1-4. The output is closed if at
least one of the channels is active.
N :
OTE
See the chapter
15.2.1.48 Binary output: TimerAct 5-8
Related FW 3.0
Description This is combined output from timer channels 5-8. The output is closed if at
least one of the channels is active.
N :
OTE
See the chapter
15.2.1.49 Binary output: TimerAct 9-12
Related FW 3.0
Description This is combined output from timer channels 9-12. The output is closed if at
least one of the channels is active.
N :
OTE
See the chapter
15.2.1.50 Binary output: TimerAct 13-16
Related FW 3.0
Description This is combined output from timer channels 13-16. The output is closed if at
least one of the channels is active.
N :
OTE
NT
InteliMains , SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
Timers for more details about timers.
Timers for more details about timers.
Timers for more details about timers.
