ComAp IM-NT-BB Reference Manual page 298

15.2.1.21 Binary output: Common Wrn
Related FW 3.0
The output is closed while there is at least one alarm of the Warning type
Description
present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed. See the chapter
Alarm management
15.2.1.22 Binary output: Common Fls
Related FW 3.0
Description The output is closed while there is at least one alarm of the Sensor fail type
present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed.See the chapter
management
15.2.1.23 Binary output: Common BOp
Related FW 3.0
Description This output closes if any "Breaker Open" type alarm appears. The output
opens if no BO type alarm is active (pressing of fault reset button is not
required).
15.2.1.24 Binary output: Common BOR
Related FW 3.0
Description This output closes if any "Breaker Open with fault reset" type alarm appears.
The output opens if no BOR type alarm is active (pressing of fault reset
button is required).
15.2.1.25 Binary output: Common Al
Related FW 3.0
Description The output is closed while there is at least one alarm of the Alarm only type
present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed. See the chapter
Alarm management
NT
InteliMains , SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
for more information.
for more information.
for more information.
Alarm
298
