14.2.1.71 Binary input: ForceValueIn 8
Related FW 3.0
This input activates the Force value #8 block. If the input is active, the value
Description
of the setpoint, to which the Force value #8 block is configured, will be
overriden by value of the alternative setpoint assigned to the Force value #8
block.
N :
OTE
If there are more than one force value blocks configured onto one setpoint
then the highest priority has the block with the lowest index (i.e. the first
active block according to the list displayed in GenConfig in the Force value
window at the related setpoint).
N :
OTE
Watch a training video about force value function here:
http://www.comap.cz/support/training/training-videos/.
N :
OTE
See an example in the description of the binary input
14.2.1.72 Binary input: ForceValueIn 9
Related FW 3.0
Description This input activates the Force value #9 block. If the input is active, the value
of the setpoint, to which the Force value #9 block is configured, will be
overriden by value of the alternative setpoint assigned to the Force value #9
block.
N :
OTE
If there are more than one force value blocks configured onto one setpoint
then the highest priority has the block with the lowest index (i.e. the first
active block according to the list displayed in GenConfig in the Force value
window at the related setpoint).
N :
OTE
Watch a training video about force value function here:
http://www.comap.cz/support/training/training-videos/.
N :
OTE
See an example in the description of the binary input
NT
InteliMains , SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
Force value 1.
Force value 1.
