ComAp IM-NT-BB Reference Manual page 260

N :
OTE
In InteliMains informational outputs SystReady, Syst res OK and other
outputs related to the power management are still active in Emerg. manual
mode even though InteliMains does not play active role in power
management and load sharing. If there are any user defined functions based
on these outputs, blocking those functions (e.g. in PLC) in Emerg. manual
mode should be considered.
C
AUTION
Be aware that all outputs related to PLC functions remain functional!
14.2.1.26 Binary input: Alt brightness
Related FW 3.0
Description This input is used to switch the IG-NT built-in terminal (display) to the
alternative backlight intensity mode (e.g. "night mode"). The alternative
intensity level is adjusted using the display buttons (see the operator guide
for details) while this input is active and is stored in the nonvolatile memory.
N :
OTE
A binary input with identical function (not configurable) is located in the power
connector of the external IG-Display and IS-Display modules.
14.2.1.27 Binary input: PulseCounter 1
Related FW 3.0
Description This is the input of the PulseCounter #1 module. The module counts pulses
at the input and if the input pulses counter reaches value given by the
setpoint ConvCoefPulse1, the counter value
Statistic) is increased by 1 and input pulses conter is reset to 0. Both counter
value and input pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy
or fuel meters with pulse outputs.
N :
OTE
Minimal pulse width as well as minimal pause between two succesive pulses
is 100ms.
N :
OTE
The counter value can be reset in the InteliMonitor statistics window.
NT
InteliMains , SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
!
PulseCounter 1 (in the group
260
