04 | Keysight | FieldFox Handheld Analyzers - Configuration Guide

FieldFox RF and Microwave (Combination) Analyzers

FeldFox RF and microwave (combination) analyzer models
Step 1. Select the model that provides the desired frequency range.
Model Description
N9913A 4 GHz FieldFox RF analyzer
N9914A 6.5 GHz FieldFox RF analyzer
N9915A 9 GHz FieldFox microwave analyzer
N9916A 14 GHz FieldFox microwave analyzer
N9917A 18 GHz FieldFox microwave analyzer
N9918A 26.5 GHz FieldFox microwave analyzer
N9950A 32 GHz FieldFox microwave analyzer
N9951A 44 GHz FieldFox microwave analyzer
N9952A 50 GHz FieldFox microwave analyzer
Step 2. Select optional measurement capabilities.
Any of these options can easily be added as a software upgrade in the future.
Exception: Option 112 is only applicable to N991xA models. It is not applicable to N995xA models.
FieldFox RF and microwave (combination) analyzer options
Option Description
CAT/vector network analysis
010 VNA time domain
112 QuickCal
210 VNA transmission/reflection
211 VNA full 2-port S-parameters
212 1-port mixed-mode S-parameters
215 TDR cable measurements
308 Vector voltmeter
Spectrum analysis
209 Extended range transmission analysis (ERTA)
233 Spectrum analyzer
235 Pre-amplifier
236 Interference analyzer and spectrogram
238 Spectrum analyzer time gating
312 Channel scanner
350 Real-time spectrum analyzer (RTSA)
351 I/Q Analyzer (IQA)
355 Analog demodulation
Power measurements
208 USB power sensor meas. versus frequency
302 USB power sensor support
310 Built-in power meter
330 Pulse meas. with USB peak power sensor
System features
030 Remote control capability
307 GPS receiver
309 DC bias variable-voltage source
Windows based software
89601B 89600 VSA Software
1. Usable to 5 kHz
2. List of compatible sensors available from www.keysight.com/find/fieldfoxsupport
3. Requires CPU2 fast processor. See page 6, FAQ #13
CAT and VNA frequency
30 kHz to 4 GHz
30 kHz to 6.5 GHz
30 kHz to 9 GHz
30 kHz to 14 GHz
30 kHz to 18 GHz
30 kHz to 26.5 GHz
300 kHz to 32 GHz
300 kHz to 44 GHz
300 kHz to 50 GHz
Prerequisite options/notes
Requires 210, recommend 211
Not available for N995xA models. See page 5, FAQ #9
Recommend ordering a cal kit
Requires 210, recommend ordering a cal kit
Requires 210 and 211
-
210 and 211 required to obtain full VVM functionality. See page 5, FAQ #8
Requires 233 and 210. Recommend 307. Requires two FieldFoxes. See page 6, FAQ # 10.
-
Requires 233
Requires 233
Requires 233
Requires 233
Requires 233, Recommend 235.
3
Requires 233
3
Requires 233
Requires 302
Need to order USB power sensor
No power sensor required. See page 8, FAQ #1
Need to order USB peak power sensor. See page 9, FAQs #7 and #8
Requires an iOS device
Need to order GPS antenna, N9910X-825. See page 9, FAQ #3
-
Requires 233
3
SA frequency Test port connectors
1
100 kHz to 4 GHz Type-N (f)
100 kHz to 6.5 GHz Type-N (f)
100 kHz to 9 GHz Type-N (f)
100 kHz to 14 GHz Type-N (f)
100 kHz to 18 GHz Type-N (f)
100 kHz to 26.5 GHz 3.5 mm (m)
9 kHz to 32 GHz NMD 2.4 mm (m)
9 kHz to 44 GHz NMD 2.4 mm (m)
9 kHz to 50 GHz NMD 2.4 mm (m)
2
