10 | Keysight | FieldFox Handheld Analyzers - Configuration Guide

FieldFox Microwave Vector Network Analyzers

FieldFox microwave vector network analyzer models
Step 1. Select the model that provides the desired frequency range.
Model Description
N9925A 9 GHz FieldFox microwave VNA
N9926A 14 GHz FieldFox microwave VNA
N9927A 18 GHz FieldFox microwave VNA
N9928A 26.5 GHz FieldFox microwave VNA
A standard N992xA FieldFox microwave VNA includes transmission/reflection measurement capability. Additional functionality such as
full 2-port S-parameters can be added using the options listed below.
Step 2. Select optional measurement capabilities.
Any of these options can easily be added as a software upgrade in the future.
FieldFox microwave vector network analyzer options
Option Description
Vector network analysis / CAT
010 VNA time domain
112 QuickCal
211 VNA full 2-port S-parameters
212 1-port mixed-mode S-parameters
215 TDR cable measurements
305 Cable and antenna analyzer
308 Vector voltmeter
Power measurements
208 USB power sensor meas. versus frequency
302 USB power sensor support
310 Built-in power meter
330 Pulse meas. with USB peak power sensor
System features
030 Remote control capability
307 GPS receiver
309 DC bias variable-voltage source
1. List of compatible sensors available from www.keysight.com/find/fieldfoxsupport
Frequency
30 kHz to 9 GHz
30 kHz to 14 GHz
30 kHz to 18 GHz
30 kHz to 26.5 GHz
Prerequisite options/notes
Recommend 211
See page 11, FAQ #7
-
Requires 211
Requires 305
-
211 required to obtain full VVM functionality. See page 11, FAQ #5
Requires 302
Need to order USB power sensor
1
No power sensor required. See page 8, FAQ #1
Need to order USB peak power sensor. See page 9, FAQs #7 and #8
Requires an iOS device
Need to order GPS antenna, N9910X-825. See page 9, FAQ #3
-
Test port connectors
Type-N (f)
Type-N (f)
Type-N (f)
3.5 mm (m)
