FieldFox Microwave Vector Network Analyzer FAQs

Question
1. What is included with a base
N992xA analyzer?
2. What is included with N992xA
Option 211?
3. What is included with N992xA
Option 010?
4. What is included with N992xA
Option 305?
5. What is included with N992xA
Option 308?
6. If I have the full 2-port VNA with
time domain, why would I order
Option 305? What additional
functionality is available?
7. What is included with N992xA
Option 112?
Additional FAQs on pages 8 and 9.
Answer
– Measurements: Transmission/reflection or S21 and S11, magnitude and phase
– Calibrations: CalReady, OSL, response, and enhanced response cal
– Option 211 adds full 2-port S-parameter capability
– Measurements: All four S-parameters (S11, S21, S22, S12), magnitude and phase
– Calibrations: CalReady, OSL, response, enhanced response, and full 2-port cal
– S11/S21 in time domain. To get time domain data for all four S-parameters and full 2-port cal, order Option 211
– View both time and frequency domain data at the same time
– Low-pass, impulse, and band-pass modes
– Minimum, normal, and maximum window
– Gating
– Measurements: DTF (dB, linear, VSWR), return loss and DTF, return loss (dB), and 1-port cable loss, 2-port
insertion loss
– TDR (linear, ohm). TDR measurements require Option 215, in addition to Option 305.
– Calibrations: CalReady, OSL, and response cal
– N992xA with Option 308: 1-port cable trimming, 2-port transmission
– N992xA with Options 308 and 211: 1-port cable trimming, 2-port transmission, A/B and B/A
– Note: A/B and B/A measurements require an external source
CAT mode's basic measurements are similar to VNA measurements. The features listed below are often used for
distance-to-fault cable testing and are only available in CAT mode:
– 3-peak marker tracking for finding faults for DTF measurements
– 1-port cable loss
– Cable type selection and editing, includes the cable's velocity factor and loss
– QuickCal is included with Option 112.
– 1-port and enhanced response QuickCal with a base analyzer
– 1-port, enhanced response, and 2-port QuickCal with a full 2-port analyzer (one that has Option 211).
– QuickCal is most accurate for DUTs with 7/16 and Type-N connectors and measurement uncertainties are
provided for frequencies 18 GHz. Reduced accuracy for DUTs with 3.5 mm (m), SMA (m), or other male coaxial
connectors; performance is unspecified. QuickCal is not recommended for DUTs with 3.5 mm (f), SMA (f), or
other similar female connectors. QuickCal is not applicable to waveguide.
FAQs on pages 8 and 9 apply to all microwave FieldFox models.
