Intel® Server System R2000WF Product Family Technical Product Specification
3.2

Power Supply Module Options

There are three power supply options available for this server product family:
- 1100W AC 80 Plus Platinum – iPC AXX1100CRPS
- 1300W AC 80 Plus Titanium – iPC AXX1300TCRPS
- 750W DC 80 Plus Gold – iPC AXX750DCCRPS
iPC= Intel product code
3.2.1

Power Supply Module Efficiency

The following tables provide the required minimum efficiency level at various loading conditions. These are
provided at three different load levels: 100%, 50% and 20%.
The AC power supply efficiency is tested over an AC input voltage range of 115 VAC to 220 VAC.

Table 6. 1100 Watt AC power supply efficiency (80 Plus Platinum)

Loading
Minimum Efficiency

Table 7. 1300 Watt AC power supply efficiency (80 Plus Titanium)

Loading
Minimum Efficiency
The DC power supply efficiency is tested with a 53 V DC input.
Loading
Minimum Efficiency
38
100% of maximum
91%
100% of maximum
91%

Table 8. 750 Watt DC power supply efficiency (80 Plus Gold)

100% of maximum
88%
50% of maximum 20% of maximum
94%
50% of maximum 20% of maximum
96%
50% of maximum 20% of maximum
92%
10% of maximum
90% 82%
10% of maximum
94% 90%
10% of maximum
88% 80%
