Discharge Pluggage Switch related. Present when "Discharge Monitor" is enabled
(see Main Menu > Advanced Setup > Configuration > Discharge Monitor).
Disch Monitor
Material On Belt Switch related. Present when "Material on Belt Sw" is enabled
(see Main Menu > Advanced Setup > Configuration > Material on Belt Sw).
Material On Blt
Flow monitor related. Present when "Infeed Flow Monitor" is enabled (see Main
Menu > Advanced Setup > Configuration > Infeed Flow Monitor).
Low Infeed Flow
Drive Check related. Present when "Drive Feedback" is enabled (see Main Menu >
Advanced Setup > Configuration > Drive Feedback).
Belt Drive AtSp
Belt Drv Overld
Belt Tracking switches related. Present when "Belt Tracking Sws" is enabled (see
Main Menu > Advanced Setup > Configuration > Belt Tracking Sws).
Belt Offs Left
Belt Offs Right
Belt Err Left
Belt Err Right
Page 99 of 104
Discharge Pluggage detected
There is material on the belt
Low Infeed flow detected
Belt drive at desired speed
Belt drive overload
Belt tracking Left, first stage
Belt tracking Right, first stage
Belt tracking Left, second stage
Belt tracking Right, second stage
