Outputs
(Main Menu > Advanced Setup > Analog I/O > Outputs)
Selecting Outputs from the Analog I/O menu will present you with the following menu:
Analog Out 1...
Analog Out 2...
Analog Out 3...
Analog Out 4...
Analog Out 5...
Analog Out 6...
Analog Out 1
Selection of one of the Analog Outputs above will allow the following settings to be
configured:
Function...
Numeric Data...
Function
This setting allows you to what process value will be transmitted by this
physical analog output. The options are:
Belt Spd Demand
Feedrate
Belt Load
Belt Speed
Setpoint
Available
Always Zero
Page 60 of 104
↑
↓
↑
↓
↑
↓
