Inputs...
Outputs...
Inputs
(Main Menu > Advanced Setup > Analog I/O > Inputs)
Selecting Inputs from the Analog I/O menu will present you with the following menu:
Analog In 1...
Analog In 2...
Analog In 3...
Analog In 1
Selection of one of the Analog Inputs above will allow the following settings to be
configured:
Function...
Calibration...
Numeric Data...
Function
This setting allows you to what process value will be received by this physical
input. The options are:
Feedrate SP
Speed SP
Oloop SP
Load
Speed
Inclination
Available
Page 56 of 104
↑
↓
↑
↓
↑
↓
↑
↓
