AtSpd Connected

This is a switch (Y/N) that tells the Genetix that the drive has an "At Speed"
output and that is connected to a GCM input, which has been mapped to the
Logical input "Belt Drive AtSp".
Numeric Data
The following parameters are available for Drive Feedback:

Overld On Delay

Not at Spd On Delay

Overld On Delay
A time delay, in seconds, between the time the "Belt Drv Overld" input
comes on and the output "Belt Drive Ovld" comes on. This timer and the
output are active even if the drive is not enabled (commanded to run).
Not at Spd On Delay
The elapsed time, in seconds, allowed for the drive to come up to speed,
once enabled (commanded to run). The "Belt Drive AtSp" must come on
within this set time to prevent the output "Belt Drive NAS" from turning on.

Material on Belt Sw

Note: To enable this item, see Main Menu > Advanced Setup >Configuration >
Material on Belt Sw
A material on belt switch (MOB) is intended to provide an electromechanical
indication of the presence of material on the belt. Typical designs are: limit switch,
tilt switch, or capacitance probe.
Selection of this item will present the following menu, whose settings will
determine the functionality of this switch.
Settings...
Numeric Data...
Settings
The following settings are available for the Material on Belt Switch:
Blocking
Jog while Blocking
