Blocking
This is a switch (Y/N) that indicates whether or not it is okay to run the belt
forward in Manual mode, while the MOB is indicating that there is material on
the belt. If "Blocking" is enabled ("Y"), then this is not allowed. This is a
requirement of the NFPA for some coal feeders.

Jog OK while Blocking

This is a switch (Y/N) that indicates whether or not it is okay to jog the belt
forward while "Blocking" is enabled (see above). If this seting is turned on
("Y"), and blocking is also enabled, then it will still be possible to jog the belt
forward (see Main Menu > Feeder Control) while the MOB is indicating that
there is material on the belt.
Numeric Data
The following numeric parameters can be set for the Material on Belt Switch:

MOB Off Delay

MOB Off Delay
This parameter sets the time, in seconds, that the controller will ignore a
loss of material on the belt, before taking any action. This can be used to
prevent temporary loss of material from un-necessarily causing alarm
(nuisance trips).

Discharge Monitor

Note: To enable this item, see Main Menu > Advanced Setup >Configuration >
Discharge
A discharge pluggage switch is typically mounted below the head pulley of the
feeder and is intended to provide an indication of flow stoppage at the discharge.
Typical designs are: limit switch, paddle switch, or capacitance probe.
Selection of this item will present the following menu, whose settings will
determine the functionality of this switch.
Settings...
Numeric Data...
Settings
The following settings are available for the Material on Belt Switch:
