High mA

Full Scale

Low mA

Zero

Selecting any of the above parameters brings up the Numeric Data Entry
screen that allows you to assign or edit the numeric value.
High mA
This is the value that represents the maximum analog signal that will be
received. If an analog input calibration has been performed then this value
will have been assigned automatically by that process. Alternatively it may
be entered directly here.
Full Scale
This is the maximum process value that will be assigned to the maximum
analog input value. The Full Scale value is entered in engineering units
representing the process value. For example if the analog input function is
set to Feedrate Setpoint, then this value would be set in units of rate (i.e.
lb/min, kg/min).
Low mA
This is the value that represents the minimum analog signal that will be
received. If an analog input calibration has been performed then this value
will have been assigned automatically by that process. Alternatively it may
be entered directly here
Zero
This is the minimum process value that will be assigned to the minimum
analog input value. The Zero value is entered in engineering units
representing the process value. For example if the analog input function is
set to Feedrate Setpoint, then this value would be set in units of rate (i.e.
lb/min, kg/min).
Analog In 2
For this analog input to be present in the menu, a second Expansion Analog Card
must be enabled (see Main Menu > Advanced Setup > Configuration > Expansion
Analog Card 1 ).
If present this analog input can be configured exactly as Analog Input 1, above.
Analog In 3
For this analog input to be present in the menu, a third Expansion Analog Card
must be enabled (see Main Menu > Advanced Setup > Configuration > Expansion
Analog Card 2 ).
If present this analog input can be configured exactly as Analog Input 1, above.
