start at this speed, limited only by the acceleration set by the user (see Main
Menu > Advanced Setup > Process Control > Accel/Decel). After jumping to
this initial speed, closed loop control takes over and regulates the speed
appropriately.
Numeric Data...
These are various data that affect feeder control.
Belt Reverse Delay
This is a time delay, set in seconds, that holds off reversing the belt if it is
running. This allows the motor to coast down before re-starting in a different
direction.

Limits

(Main Menu > Advanced Setup > Limits)
Limits provide alarm functionality for selected process parameters. If the actual value
moves outside of the limits set here, Logical outputs are set and/or clamping can take
place. All Limits have "Delay" settings to prevent nuisance alarms if the process
variable only momentarily exceeds its Limit. The process values that may have Limits
set are:
Feedrate...
Load...
Speed...
Setpoint...
Belt Speed Demand...
